ABB E-Klips AH814-GM1926 Trägerklammer waagrecht Rail bracket Spring steel 7TCA084030R0652 25 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
AH814-GM1926 E-Clips form bracket horizontally to 8-14mm + pipe clamp 19-26mm, lockable
- Support thickness (T): Suitable for flanges with a thickness of 8 mm up to 14 mm.
- Line protection diameter: Suitable for pipes / hoses with an external diameter of 19 mm to 26 mm.
- PG size: Compatible with PG types 13.5 and 16.
- Load capacity: Maximum vertical load-carrying capacity of 12 kg.
- Simple assembly: Quick installation on steel constructions only with simple tools (such as a hammer), without the need for drilling holes or additional screws.
- Material & Quality: Made of low carbon steel (grade C67S) in accordance with DIN EN 10132-4.
- Surface (F8+): Two-stage, chrome-free zinc phosphate coating with water-resistant top layer, providing over 600 hours of protection in the salt spray test in accordance with ASTM-B695-90.
Technical specifications
- Suitable for an external diameter of 19-26 mm
- Product type
Rail bracket
- Material
Spring steel
- Content
25 pc(s)
- Shape
AH814-GM1926 (combination of AH type and GM type clip)
- Material properties
tempered
corrosion-protected
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3744126 ABB E-Klips AH814-GM1926 Trägerklammer waagrecht Rail bracket Spring steel 7TCA084030R0652 25 pc(s)
User & Safety Instructions
User & Safety Instructions 3744126 ABB E-Klips AH814-GM1926 Trägerklammer waagrecht Rail bracket Spring steel 7TCA084030R0652 25 pc(s)
Description
E-Klips® AH814-GM1926 – The efficient solution for your line protection Optimize your assembly times with the ABB E-Klips® carrier clamp AH814-GM1926. For over 40 years the E-clip system stands for a fast, simple and reliable fixing at different designs.This robust clamp enables the secure fixing of pipe protection tubes (Ø 19-26 mm) at steel carriers with a flange thickness of 8-14 mm – completely without drilling or welding. With revolutionary F8+ zinc phosphate coating, you can enjoy outstanding, durable corrosion protection that can withstand even the most demanding indoor and outdoor environments. Rely on tested quality according to EN ISO 9001 and save valuable working time with maximum reliability.
This text is machine translated.
This text is machine translated.
Scope of delivery
- 25 items per pack
