ABB E-Klips ECL-1519 Trägerklammer Trägerclip für Träger Rail bracket Spring steel 7TCA084030R0990 100 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
ECL-1519 E-Clips carrier clip for carrier 8-12mm, for cable 15-19mm
- Application area: Specially designed for the attachment of individual flexible wires at steel constructions.
- Dimensions: Suitable for flange thicknesses (T) of 8–12 mm and line diameters of 15–18 mm.
- Material: Made of high-quality, hardened spring steel of the grade C67S according to DIN EN 10132-4.
- Surface protection (F8+): High-resistant, chrome-free zinc phosphate coating with water-resistant top layer; offers over 600 hours protection in salt spray test.
- Easy installation: Quick installation without drilling or additional screws; only simple tools such as a hammer are required.
Technical specifications
- Suitable for cable diameters from 15 mm to 18 mm
- Flange thickness (T): Suitable for supporting flanges from 8 mm up to 12 mm
- Product type
Rail bracket
- Material
Spring steel
- Content
100 pc(s)
- Shape
ECL (support bracket for single cables with high flange thickness)
- Material properties
tempered
corrosion-protected
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3744131 ABB E-Klips ECL-1519 Trägerklammer Trägerclip für Träger Rail bracket Spring steel 7TCA084030R0990 100 pc(s)
User & Safety Instructions
User & Safety Instructions 3744131 ABB E-Klips ECL-1519 Trägerklammer Trägerclip für Träger Rail bracket Spring steel 7TCA084030R0990 100 pc(s)
Description
The E-Clips mounting bracket ECL-1519 offers a highly efficient and reliable solution for mounting individual wires on carrier profiles with a thickness of 8 to 12 mm. Thanks to the proven spring steel fastening system from ABB, time-consuming work such as drilling or screwing down additional attachments is no longer necessary. The clamp is simply applied to the flange and holds cables in the range of 15 to 18 mm securely in position. The revolutionary F8+ coating ensures the system is optimally protected against corrosion and is ideal for use indoors and outdoors with a slightly corrosive environment. Trust over 40 years of experience in fixing technology and reduce your assembly times significantly while maintaining the same high quality as per EN ISO 9001.
This text is machine translated.
This text is machine translated.
Scope of delivery
- 100 pieces
