ABB E-Klips EH-38 Trägerklammer waagrecht Rail bracket Spring steel 7TCA084030R1091 100 pc(s) (Ø x H) 7 mm x 33 mm
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
EH-38 E-clips, carrier bracket horizontal on 3-8mm, with hole horizontal 7mm
- Quick mounting: Easy installation on steel beams without drilling or welding.
- Quality-tested: Made of high-quality spring steel (C67S) in accordance with DIN EN 10132-4.
- Excellent corrosion protection: Highly resistant, chrome-free zinc phosphate coating (F8+) with over 600 hours of resistant salt spray mist.
- High load capacity: Vertical static load limit of up to 45 kg.
- Versatile use: Suitable for flange thicknesses of 3 to 8 mm for fixing junction boxes.
Technical specifications
- Clamping range (T) 3 - 8 mm
- Hardened to 400-450 HV-10 Vickers, soft-annealed and oiled
- Product type
Rail bracket
- Dim
(Ø x H) 7 mm x 33 mm
- Material
Spring steel
- Content
100 pc(s)
- Shape
Type EH
- Material properties
tempered
corrosion-protected
- Width
7.5 mm
- Height
33 mm
- (Ø)
7 mm
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3744148 ABB E-Klips EH-38 Trägerklammer waagrecht Rail bracket Spring steel 7TCA084030R1091 100 pc(s) (Ø x H) 7 mm x 33 mm
User & Safety Instructions
User & Safety Instructions 3744148 ABB E-Klips EH-38 Trägerklammer waagrecht Rail bracket Spring steel 7TCA084030R1091 100 pc(s) (Ø x H) 7 mm x 33 mm
Description
The ABB E-clips EH-38 carrier clamp is the ideal solution for a fast, reliable and cost-efficient mounting on steel structures. Tried and tested for over 40 years, this system allows the mounting of junction boxes without the need for complex drilling or the use of additional screws.
Thanks to the innovative two-stage zinc phosphate coating (F8+) the clamp offers a long-lasting corrosion protection, which can withstand even the most demanding indoor and outdoor environments. Simple installation with standard tools saves valuable working time at the construction site, while EN ISO 9001 certification guarantees the highest product safety and quality.
This text is machine translated.
Thanks to the innovative two-stage zinc phosphate coating (F8+) the clamp offers a long-lasting corrosion protection, which can withstand even the most demanding indoor and outdoor environments. Simple installation with standard tools saves valuable working time at the construction site, while EN ISO 9001 certification guarantees the highest product safety and quality.
This text is machine translated.
Scope of delivery
- 100 pieces per pack unit
