ABB E-Klips FC-10T Trägerklammer waagrecht Rail bracket 50 mm Spring steel 7TCA084220R0152 25 pc(s) (L x W x H) 50 x 42
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Support screw clamp horizontal up to 19mm, solid, with M10
- Threaded rod connection: Integrated M10-thread for direct attachment of threaded rods.
- High load capacity: Maximum vertical load limit of 250 kg.
- Flexible clamping range: Suitable for steel carrier flange thicknesses up to 19 mm.
- Robust material: Made of hardened spring steel of the grade C67S according to DIN EN 10132-4.
- Mounting without drilling: Enables fast and easy installation without drilling or additional screws.
Technical specifications
- 72 hours of salt spray resistant (in accordance with ASTM-B117-90 / DIN EN 50021)
- Maximum load carrying capacity: 250 kg.
- Hardened to a final hardness of 400-450 HV-10 Vickers
- Product type
Rail bracket
- Dim
(L x W x H) 50 x 42 x 45 mm
- Material
Spring steel
- Content
25 pc(s)
- Shape
FC
- Thread size
M10
- Material properties
tempered
corrosion-protected
- Width
42 mm
- Height
45 mm
- Length
50 mm
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3744178 ABB E-Klips FC-10T Trägerklammer waagrecht Rail bracket 50 mm Spring steel 7TCA084220R0152 25 pc(s) (L x W x H) 50 x 42
User & Safety Instructions
User & Safety Instructions 3744178 ABB E-Klips FC-10T Trägerklammer waagrecht Rail bracket 50 mm Spring steel 7TCA084220R0152 25 pc(s) (L x W x H) 50 x 42
Description
Optimize your assembly processes with the proven E-Klips® spring steel mounting systems from ABB. The FC-10T carrier terminal has been offering a reliable solution for fast and easy attachment of M10 threaded rods to steel structures for over 40 years. Thanks to the innovative design, you only need simple tools for installation and avoid time-consuming drilling or welding.
The terminal has a high-quality galvanic zinc (surface F1), which offers solid corrosion protection for indoor use. With an impressive load capacity of 250 kg, the FC-10T is the ideal choice for demanding applications, such as the installation of lighting systems, cable ducts or suspended ceilings. Trust tested quality in accordance with EN ISO 9001 for your installation projects.
This text is machine translated.
The terminal has a high-quality galvanic zinc (surface F1), which offers solid corrosion protection for indoor use. With an impressive load capacity of 250 kg, the FC-10T is the ideal choice for demanding applications, such as the installation of lighting systems, cable ducts or suspended ceilings. Trust tested quality in accordance with EN ISO 9001 for your installation projects.
This text is machine translated.
Scope of delivery
- 25 items per pack
