Image similar
ABB E-Klips FH-107 Trägerklammer waagrecht Rail bracket 19.5 mm Spring steel 7TCA084030R1210 100 pc(s) (Ø x L) 10.7 mm x
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Support screw clamp horizontal to 18mm, with hole 10.7mm
- Quick mounting: Provides simple and reliable attachment to steel beams (carrier flanges) without drilling or welding.
- Excellent protection against corrosion: Equipped with a revolutionary, chrome-free zinc phosphate coating (F8+) for a high resistance of over 600 hours in salt spray test.
- Quality tested: Made of low carbon C67S grade steel in accordance with DIN EN 10132-4 and certified according to EN ISO 9001.
- Flexibility: Suitable for flange thicknesses up to 18 mm and a load capacity of up to 45 kg.
- Versatile connections: Has holes with diameters of 10.7 mm and 6.5 mm for fixing threaded rods or other accessories.
Technical specifications
- DIN-STANDARD DIN EN 10132-4
- Surface: Zinc phosphate coating (F8+), chrome-free, waterproof cover
- Corrosion protection: At least 600 hours of salt spray resistant
- Flange thickness (T): Max. 18 mm
- Max. load carrying capacity 45 kg.
- Tightening torque 3 Nm
- EN ISO 9001 certification
- Product type
Rail bracket
- Dim
(Ø x L) 10.7 mm x 19.5 mm
- Material
Spring steel
- Content
100 pc(s)
- Shape
FH-107
- Thread size
M10
- Material properties
tempered
corrosion-protected
- Width
10.7 mm
- Length
19.5 mm
- (Ø)
10.7 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3744164 ABB E-Klips FH-107 Trägerklammer waagrecht Rail bracket 19.5 mm Spring steel 7TCA084030R1210 100 pc(s) (Ø x L) 10.7 mm x
User & Safety Instructions
User & Safety Instructions 3744164 ABB E-Klips FH-107 Trägerklammer waagrecht Rail bracket 19.5 mm Spring steel 7TCA084030R1210 100 pc(s) (Ø x L) 10.7 mm x
Description
Efficient mounting without compromises - The E-clips carrier clamp FH-107.
Optimize your installation processes with the proven ABB E-clip system. For over 40 years E-Clips stands for a fast, tool-protecting mounting in various designs. The FH-107 carrier terminal cuts time-consuming holes or additional screwing onto steel carriers. Thanks to its unique two-stage zinc phosphate coating (F8+), it provides exceptionally long corrosion protection while meeting the highest environmental requirements – Ideal for indoor and outdoor use. With a vertical load carrying capacity of 45 kg and flexible connection options for threaded rods, it is the ideal solution for modern lighting systems, cable channels and suspensions. You can rely on certified quality and save valuable assembly time on the construction site.
This text is machine translated.
Optimize your installation processes with the proven ABB E-clip system. For over 40 years E-Clips stands for a fast, tool-protecting mounting in various designs. The FH-107 carrier terminal cuts time-consuming holes or additional screwing onto steel carriers. Thanks to its unique two-stage zinc phosphate coating (F8+), it provides exceptionally long corrosion protection while meeting the highest environmental requirements – Ideal for indoor and outdoor use. With a vertical load carrying capacity of 45 kg and flexible connection options for threaded rods, it is the ideal solution for modern lighting systems, cable channels and suspensions. You can rely on certified quality and save valuable assembly time on the construction site.
This text is machine translated.
Scope of delivery
- 100 items per pack
