ABB ESB63-20N-06 R0620 Remote switch 2 makers 63 A Piece 1 pc(s)
EAN:
Part number:
Item no:
Product type
Remote switch
No. of pins
4-pin
Current load
63 A
Packaging type
Piece
Type
ESB63-20N-06 R0620
Technical specifications
- Packaging type
Piece
- Product type
Remote switch
- Type
ESB63-20N-06 R0620
- No. of pins
4-pin
- Contact type
2 makers
- Auxiliary contact type
2 makers
- Control voltage (min.)
230 V AC
230 V DC
- Control voltage (max.)
230 V AC
230 V DC
- Control voltage range
230, 230 - 230, 230 V AC, V DC
- Switching voltage (min.)
220 V AC
220 V DC
- Switching voltage (max.)
400 V DC/AC
- Permanent current (max.)
63 A
- Current load
63 A
IP20
- Width
54 mm
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3783961 ABB ESB63-20N-06 R0620 Remote switch 2 makers 63 A Piece 1 pc(s)
Description
4-pole contactor ESB63 with 54 mm width controls 3-phase loads up to 63 A (NC contacts up to 30 A) and is available in different contact assignments and coil voltages. They control electrical heaters, water heaters, motors for pumps, ventilation and other drives as well as lighting. Through an integrated coil circuit they work with AC as well as with DC control voltages. The devices are therefore absolutely free of humming and low while switching. Accessories such as auxiliary switches, sealing caps and a spacer complement the range. ESB63 have installation design and meet the EN61095 household standard, and are therefore particularly suitable for distributor installation.
