ABB MC1A310AR1 Mini contactor 4 makers 4 kW + auxiliary contact 1 pc(s)
EAN:
Part number:
Item no:
Product type
Mini contactor
No. of pins
3-pin
Power
4 kW
Connection
Ring terminal
Type
MC1A310AR1
Datasheet (PDF)
Technical specifications
- Product type
Mini contactor
- Type
MC1A310AR1
- No. of pins
3-pin
- Contact type
4 makers
- Auxiliary contact type
4 makers
- Control voltage (max.)
24 V AC
- Control voltage range
24 V AC (max)
- Switching voltage (max.)
690 V AC
- Permanent current (max.)
20 A
4 kW
- Features
+ auxiliary contact
- Mounting type
DIN rail
- Connection
Ring terminal
- Content
1 pc(s)
FALSE
4 kW
3
0
1
0
9 A
20 A
24-24 V
24-24 V
Other
AC
9 A
4 kW
2.2371 kW
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3104740 ABB MC1A310AR1 Mini contactor 4 makers 4 kW + auxiliary contact 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3104740 ABB MC1A310AR1 Mini contactor 4 makers 4 kW + auxiliary contact 1 pc(s)
Description
The MC1A mini contactor is a size-optimized 3-pin contactor with an integrated auxiliary contact, AC control and ring terminal connections. It provides the optimum solution when high performance is required but space is limited. These miniature contactors can be used in residential buildings, commercial buildings and many industrial applications for controlling single or three-phase loads up to 4 kW (AC-3) and 20 A (AC-1) at 690 V or for control signals. In addition, up to 6 additional auxiliary contacts can be mounted on the front or side. The contactor is suitable for DIN rail or wall mounting.
