ABB MC2A301ATJ Mini contactor 3 makers, 1 breaker 5.5 kW + auxiliary contact Piece 1 pc(s)
EAN:
Part number:
Item no:
Product type
Mini contactor
No. of pins
3-pin
Power
5.5 kW
Connection
Screws
Packaging type
Piece
Datasheet (PDF)
Technical specifications
- Packaging type
Piece
- Product type
Mini contactor
- Type
MC2A301ATJ
- No. of pins
3-pin
- Contact type
3 makers
1 breaker
- Auxiliary contact type
3 makers
- Control voltage (min.)
110 V AC
- Control voltage (max.)
120 V AC
- Control voltage range
110 - 120 V AC
- Switching voltage (max.)
690 V AC
- Permanent current (max.)
20 A
5.5 kW
- Features
+ auxiliary contact
- Mounting type
DIN rail
- Connection
Screws
- Content
1 pc(s)
FALSE
5.5 kW
3
0
0
1
12 A
20 A
110-120 V
110-110 V
Screw connection
AC
9 A
4 kW
2.2371 kW
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3104754 ABB MC2A301ATJ Mini contactor 3 makers, 1 breaker 5.5 kW + auxiliary contact Piece 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3104754 ABB MC2A301ATJ Mini contactor 3 makers, 1 breaker 5.5 kW + auxiliary contact Piece 1 pc(s)
Description
The MC2A small contactor is a size-optimized 3-pin contactor with an integrated auxiliary contact, AC control and screw connections. It provides the optimum solution when high performance is required but space is limited. These miniature contactors can be used in residential buildings, commercial buildings and many industrial applications to control single or three phase loads up to 5.5kW (AC-3) and 20A (AC-1) at 690 V or for control signals. In addition, up to 6 additional auxiliary contacts can be mounted on the front or side. The contactor is suitable for DIN rail or wall mounting.
