ABB MCRC004ATWD Mini contactor 4 breakers + auxiliary contact Piece 1 pc(s)
EAN:
Part number:
Item no:
Product type
Mini contactor
No. of pins
4-pin
Connection
Screw terminal
Packaging type
Piece
Type
MCRC004ATWD
Datasheet (PDF)
Technical specifications
- Packaging type
Piece
- Product type
Mini contactor
- Type
MCRC004ATWD
- No. of pins
4-pin
- Contact type
4 breakers
- Auxiliary contact type
4 breakers
- Control voltage (max.)
24 V DC
- Control voltage range
24 V DC (max)
- Switching voltage (max.)
240 V AC
- Permanent current (max.)
4 A
- Features
+ auxiliary contact
- Connection
Screw terminal
- Content
1 pc(s)
DIN rail
FALSE
0
4
4 A
FALSE
0
24-24 V
FALSE
Screw connection
0
0
DC
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3104511 ABB MCRC004ATWD Mini contactor 4 breakers + auxiliary contact Piece 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3104511 ABB MCRC004ATWD Mini contactor 4 breakers + auxiliary contact Piece 1 pc(s)
Description
The MCRC series of miniature auxiliary contactors are custom-designed, 4-pole DC-actuated auxiliary contactors with screw terminals. These devices offer the optimum solution when high performance is required but space is limited. Mini auxiliary contactors are used in residential buildings, commercial buildings and industrial applications to control signals and small loads up to 6 A / 240 V (AC-15). Up to 6 additional auxiliary contacts can be mounted on the front or side. These contactor relays are suitable for wall or rail mounting.
