ABB NF80EK-12 Auxiliary contactor 8 makers + surge protection 1 pc(s)
EAN:
Part number:
Item no:
Product type
Auxiliary contactor
No. of pins
8-pin
Type
NF80EK-12
Contact type
8 makers
Auxiliary contact type
8 makers
Datasheet (PDF)
Technical specifications
- Product type
Auxiliary contactor
- Type
NF80EK-12
- No. of pins
8-pin
- Contact type
8 makers
- Auxiliary contact type
8 makers
- Control voltage (min.)
48 V AC
48 V DC
- Control voltage (max.)
130 V AC
130 V DC
- Control voltage range
48, 48 - 130, 130 V AC, V DC
- Permanent current (max.)
3 A
- Features
+ surge protection
- Content
1 pc(s)
DIN-rail/screw
FALSE
8
0
3 A
FALSE
0
48-130 V
48-130 V
48-130 V
FALSE
Spring clamp connection
0
0
AC/DC
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3105107 ABB NF80EK-12 Auxiliary contactor 8 makers + surge protection 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3105107 ABB NF80EK-12 Auxiliary contactor 8 makers + surge protection 1 pc(s)
Description
The 8-pin LF auxiliary contactors are used for switching auxiliary and control circuits. They have an electronic coil interface that allows a wide control voltage range and can handle large control voltage fluctuations. LF auxiliary contactors have built-in overvoltage protection and do not require any additional quenching circuits.
