ABB NFZ40E-21 Switch 4 makers 1.7 W 24 V 3 A + surge protection Piece 1 pc(s)
EAN:
Part number:
Item no:
Product type
Switch
No. of pins
4-pin
Nominal voltage
24 V
Current load
3 A
Power
1.7 W
Datasheet (PDF)
Technical specifications
- Packaging type
Piece
- Product type
Switch
- Type
NFZ40E-21
- No. of pins
4-pin
- Contact type
4 makers
- Auxiliary contact type
4 makers
- Nominal voltage
24 V
- Control voltage (min.)
24 V DC
- Control voltage (max.)
250 V AC
- Control voltage range
24 - 250 V AC
- Permanent current (max.)
3 A
- Current load
3 A
1.7 W
- Features
+ surge protection
- Mounting type
Screws
- Connection
Axial screw terminal
- Content
1 pc(s)
DIN-rail/screw
4
0
0
24-60 V
24-60 V
20-60 V
FALSE
AC/DC
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2319930 ABB NFZ40E-21 Switch 4 makers 1.7 W 24 V 3 A + surge protection Piece 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2319930 ABB NFZ40E-21 Switch 4 makers 1.7 W 24 V 3 A + surge protection Piece 1 pc(s)
Description
The 4-pole NFZ contactor relays are used for switching auxiliary and control circuits. They have an electronic coil interface that can realize a very wide control voltage. This also allows large control voltage fluctuations to be managed. The contactor relays enable direct control through ≥24V DC 500mA PLC outputs and require a very low holding power of only 1.7W. NFZ contactor relays can withstand short voltage dips and voltage drops (according TO SEMI F47-0706) between 24...250 V 50/60 Hz. They have a built-in surge protection and do not require any additional extinguishing elements. A wide range of accessories is also available.
