ABB OTDC25U2 Isolator switch 40 A 1000 V 1 pc(s)
EAN:
Part number:
Item no:
Product type
Isolator switch
Operation type
Rotation actuator
Switching voltage
1000 V
Switching current (max.)
40 A
Number of pins
2
Datasheet (PDF)
Technical specifications
- Product type
Isolator switch
- Operation type
Rotation actuator
- Number of pins
2
- Connection
Screws
- Switching voltage
1000 V
- Switching current (max.)
40 A
IP20
- Content
1 pc(s)
- Type
OTDC25U2
0
0
40 A
2
1000-1000 V
IP20
0
1
FALSE
FALSE
Screw connection
FALSE
Short thumb-grip
TRUE
FALSE
TRUE
1 kA
FALSE
FALSE
FALSE
TRUE
FALSE
1000 V
FALSE
FALSE
Built-in device fixed built-in technique
FALSE
1
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3100341 ABB OTDC25U2 Isolator switch 40 A 1000 V 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3100341 ABB OTDC25U2 Isolator switch 40 A 1000 V 1 pc(s)
Description
The manually operated OTDC series switch disconnectors are a cost-effective and reliable solution for a wide range of industrial DC applications. The OTDC series switches currents from 16 A to 32 A smoothly at voltages of 600 V DC. Thanks to different mounting options, the switches offer a high degree of flexibility and efficiency in planning. The series has a UL approval and ensures a reliable switch-off performance at all currents, without compromising safety. In addition, the switches are designed to be used in particularly high ambient temperatures. In addition, the power loss has been reduced by 50%. ABB offers you a wide range of accessories for these switches, such as extension shafts, handles, auxiliary switches and terminal covers. Therefore, the DC switch disconnectors can be used in the most demanding applications.
