ABB Position sensor 1 pc(s) CM-ENS.13S (W x H) 22.5 mm x 85.6 mm
EAN:
Part number:
Item no:
Product type
Position sensor
Connector
Screw-fit
Type
CM-ENS.13S
Content
1 pc(s)
Max. operating voltage
110 V
Datasheet (PDF)
Technical specifications
- Product type
Position sensor
- Type
CM-ENS.13S
- Content
1 pc(s)
- Max. operating voltage
110 V
- Operating voltage
110 V (max)
- Connector
Screw-fit
- Width
22.5 mm
- Height
85.6 mm
- Dim
(W x H) 22.5 mm x 85.6 mm
22.5
85.6 mm
103.7 mm
FALSE
Screw connection
0
0
1
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2328673 ABB Position sensor 1 pc(s) CM-ENS.13S (W x H) 22.5 mm x 85.6 mm
User & Safety Instructions
User & Safety Instructions 2328673 ABB Position sensor 1 pc(s) CM-ENS.13S (W x H) 22.5 mm x 85.6 mm
Description
THE CM-ENS.13S is a relay from THE CM family for level monitoring and level control. The rated control supply voltage is 110-130 V AC, or 220-240 V AC. Output: 1 changeover contact (250 V / 4A). It monitors and controls levels and mixing ratios of conductive liquids. It is used for filling and emptying applications, for dry running protection of pumps and for signaling the status of the monitored level. Working current principle. The sensitivity can be set using the potentiometer mounted on the front. Various electrodes, as well as a sealable clear cover for protection against unauthorized adjustment of the settings are available as accessories. The device is available with double chamber box screw terminals, or push-in terminals.
