ABB TMD 32-320 XT2 4P Circuit breaker 1 pc(s) Adjustment range (amperage): 32 - 320 A Piece
EAN:
Part number:
Item no:
Product type
Circuit breaker
Amperage adjustment range (max.)
320 A
Packaging type
Piece
Type
TMD 32-320 XT2 4P
Amperage adjustment range (min.)
32 A
Datasheet (PDF)
Technical specifications
- Packaging type
Piece
- Product type
Circuit breaker
- Type
TMD 32-320 XT2 4P
- Amperage adjustment range (min.)
32 A
- Amperage adjustment range (max.)
320 A
- Adjustment range (amperage)
32 - 320 A
- No. of pins
4-pin
- Content
1 pc(s)
FALSE
TRUE
Other
FALSE
TRUE
320 A
320 A
0
0
0
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3105935 ABB TMD 32-320 XT2 4P Circuit breaker 1 pc(s) Adjustment range (amperage): 32 - 320 A Piece
User & Safety Instructions
User & Safety Instructions 3105935 ABB TMD 32-320 XT2 4P Circuit breaker 1 pc(s) Adjustment range (amperage): 32 - 320 A Piece
Description
Compact circuit breaker for system protection according to EN 60947-2 (DIN VDE 0660, part 101),
Compact circuit breakers in accordance with EN 60947-3 (DIN VDE 0660, part 107).
The Tmax XT compact power/switch disconnectors meet the different system requirements of DC and AC power supply systems. Tmax XT with thermo-magnetic or electronic triggers can be used to protect power distribution units, cables, generators and motors. Many of these circuit breakers can also be used in communication systems. Extensive connection kits, mechanical and electrical accessories as well as version conversion kits (pluggable/extendable) are available. Different fieldbus and IP communication protocols can be used.
The installation process is, thanks to the
Bluetooth and Ekip connectivity for mobile
Devices, simplified.
The connectivity built into the SACE Tmax XT Series
Links smartphones, tablets, and PCs to
Real-time with data analysis tools on the ABB
AbilityTM Cloud platform
