Three plastic containers in red, yellow, and blue, arranged side by side. Each has a droplet-shaped opening at the top.

1/2

Datasheet (PDF)

Fast track dispatch on Mon, 14 Sep

134 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Total (€ 16.80 / piece)

€ 16.80

plus VAT.

Report legal concerns

Siren with flashing light

Highlights & Details

Sound pressure 100 dB/1 m
Compact size

Technical specifications

Product type: Alarm sounder + flashing light

Colour: Red

Flash rate: 120 flashes/min

Max. sound pressure: 100 dB

Operating voltage: 12 V DC

: IP54

Used at: Indoors
Outdoors

Width: 73 mm

Height: 122 mm

Depth: 43 mm

Dim: (W x H x D) 73 x 122 x 43 mm

Factory colour: Multicolour

Material (details): Housing made of ABS

SPL: 100 dB/ 1 m.

Current consumption: 200 mA

Operating temperature: -10 - +50 °C

Operating voltage: 9 - 12 V DC

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 750995 ABUS SG1681 Alarm sounder + flashing light 100 dB Red Indoors, Outdoors 12 V DC

User & Safety Instructions

User & Safety Instructions 750995 ABUS SG1681 Alarm sounder + flashing light 100 dB Red Indoors, Outdoors 12 V DC

Conformity certificate

Conformity certificate 750995 ABUS SG1681 Alarm sounder + flashing light 100 dB Red Indoors, Outdoors 12 V DC

Description

The weather-proof construction and the especially small dimensions allow this siren with flashing light to be used in both indoor and covered outdoor areas. The siren generates an intermittent signal with a sound pressure of over 100 dB. The siren and the flashing light can be separately controlled.
