ACV 40-AD-REMOTE Automotive relay 12 V DC 1.50 A 1 maker
EAN:
Part number:
Item no:
Product type
Automotive relay
Coil nominal voltage
12 V DC
Contact type
1 maker
Connection
Open end cable
Switching voltage (max.)
14.40 V DC
Number
Total (€ 17.64 / piece)
€ 31.08
-43 %
€ 17.64
plus VAT.
Only 8 Piece(s) available
Technical specifications
- Product type
Automotive relay
- Type
40-AD-REMOTE
- Coil nominal voltage
12 V DC
- Min. pick-up voltage
7 V DC
- Max. pick-up voltage
12 V DC
- Contact type
1 maker
- Connection
Open end cable
- Switching voltage (max.)
14.40 V DC
- Switching current (max.)
1.50 A
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2587206 ACV 40-AD-REMOTE Automotive relay 12 V DC 1.50 A 1 maker
Description
N/O relay Electronic N/O relay: Noiseless insensitive to vibrations Low coupling capacities between input and output No mechanical wear No interference by magnetic fields No emitting of magnetic fields No error message in sound systems or lighting systems Remote signal generation via LS-tapping of the car radio Switching relay for tapping a back-up signal from the rear light Note: Connection: 12V voltage / ground / any input signal from +2V to +14.2V yellow: Terminal 30 black: Terminal 85 green: Terminal 86 blue: Terminal 87 for the following application: Relay 12VRemote relay 12V can be used as switching relay: Take-off of the rear light signal for camera installationAmp remote production from loudspeaker BTL voltage Technical data: Operating voltage: 7V-12V DC switching voltage: 2V-14.4Vpower consumption Hibernation mode: <10mAMaximale Current output: 1.5Asec: Switch-on delay: 0.1 <.100kOhm
This text is machine translated.
This text is machine translated.
Hints
Switch current information refers to peak current. Full details free to download from our comprehensive product documents library.
