akYtec PRM.24.2 138118 PLC add-on module 24 V DC
Part number:
Item no:
Highlights & Details
PRM.24.2, expansion module for PR200
- Can be extended to PR200, PR102, PR103, PR205 with additional inputs and outputs without network protocols
- Configurable inputs and outputs with different signals to choose from
- Power supply independent of the main unit
- Same high-speed performance as the main unit
- Safety output status
- Easy to connect, remove and exchange
- Electrical isolation between power supply and I/O groups
- Wide ambient temperature range
Technical specifications
- Min Operating voltage 19 V DC
- Max. Operating voltage 30 V DC
- Operating voltage: 24 V DC
- Display: No.
- Product type: PLC add-on module
- Number of analogue inputs (max.) (4...20 mA, 0...10 V, Pt1000, NTC, PTC, 0...300 kOhm, digital signal, etc.): 4
- Number of relay outputs (max.): 4
- Height: 58 mm
- Length: 108 mm
- Width 88 mm
- IP protection class IP20
- Device type PRM.24.2
- Manufacturer part number: 138118
- Dimensions 108 x 88 x 58 mm (L x W x H)
- Mounting type (details): DIN rail (control panel / distribution box)
- Real-time clock: No.
- Maximum ambient temperature: +55 °C
- Minimum ambient temperature -20°C.
- Product type
PLC add-on module
- No. of analogue inputs
4
- No. of analogue outputs
2
- No. of digital inputs (max.)
8
- No. of inputs (max.)
8
- No. of outputs (max.)
4
- No. of relay outputs (max.)
4
- Min. operating voltage
19 V DC
- Operating voltage
19 - 30 V DC
- Max. operating voltage
30 V DC
- Operating voltage
24 V DC
- Height
58 mm
- Length
108 mm
- Width
88 mm
IP20
- Type
PRM.24.2
- Manufacturer part #
138118
- Dim
(L x W x H) 108 x 88 x 58 mm
- Display
No
- Real-time clock
No
- Max. ambient temperature
-20 °C
- Min. ambient temperature
+55 °C
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3553337 akYtec PRM.24.2 138118 PLC add-on module 24 V DC
User & Safety Instructions 3553337 akYtec PRM.24.2 138118 PLC add-on module 24 V DC
Description
The SIMATIC S7-200 family offers a broad spectrum of modules suitable for the most varied applications. The newly available CPU types and expansion modules enable universal automation concepts with 10 to 248 inputs/outputs. The products of the S7-200 family which are optimally matched to each other also make it easy to change and expand the automation solution in the future.
Area of application e.g.:small and special machines: Packaging, encompassing and wrapping machines .Food industry: kneading, cutting machines, Mixing .Laboratory: Lab mixer, steam ovens, vacuum pumps, suction mechanisms.
The CPUs are each offered in 5 different variants, with various connection and control voltages. The PPI interface built into all CPUs enables point-to-point connections to PG/PC, SIMATIC OP, expanded SIMATIC S7-200 and user-defined end devices (printer, bar code reader). With PG/PC or OP as master, a maximum of 31 SIMATIC S7-200 devices can be connected together. If additional inputs/outputs are required, a variety of different expansion modules is available. These are simply linked to the CPU through a connector.
Area of application e.g.:small and special machines: Packaging, encompassing and wrapping machines .Food industry: kneading, cutting machines, Mixing .Laboratory: Lab mixer, steam ovens, vacuum pumps, suction mechanisms.
The CPUs are each offered in 5 different variants, with various connection and control voltages. The PPI interface built into all CPUs enables point-to-point connections to PG/PC, SIMATIC OP, expanded SIMATIC S7-200 and user-defined end devices (printer, bar code reader). With PG/PC or OP as master, a maximum of 31 SIMATIC S7-200 devices can be connected together. If additional inputs/outputs are required, a variety of different expansion modules is available. These are simply linked to the CPU through a connector.
Scope of delivery
- PRM device
- Quick guide
- Terminal blocks (set)
- Connecting cable
