Amewi Micro servo AMXRacing AM1102HB Analogue servo Gear box material: Plastic Connector system: JR
EAN:
Part number:
Item no:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 9.24
3
5% = € 0.48
€ 8.76
5
7% = € 0.68
€ 8.56
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 9.24 / piece)
€
Technical specifications
- Dead Band: 1μs
- Operating frequency 1520μs / 330Hz
- Motor: Coreless motor
- Operating voltage DC 3.5 V
- Gear: Plastic
- Housing: Plastic
- Regulating speed (4.8V): 0.09sec/60°
- Displacement force (4.8V): 0,24kg/cm
- Cable length: 100mm
- JR connection
- Servo head 28Z
- Dim
(L x W x H) 16.3 x 8.4 x 17.5 mm
- Length
16.3 mm
- Width
8.4 mm
- Height
17.5 mm
- Weight
2.1 g
- Actuation time at 4.8 V
0.09 s
- Gear box
Plastic
- Servo technology
Analogue servo
- Connector system
JR
- for brands
Amewi
- Voltage
Low
- Manufacturer part #
28999
- Min. operating voltage
3.5 V
- Operating voltage
3.5 - 4.8 V
- Max. operating voltage
4.8 V
- Product type
Micro servo
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3345282 Amewi Micro servo AMXRacing AM1102HB Analogue servo Gear box material: Plastic Connector system: JR
Description
Small and light-weight 4.8V micro-servo with high actuating speed and 0.24kg adjusting force at only 2.1g weight - suitable for RC aircraft and small models.
This text is machine translated.
This text is machine translated.
Scope of delivery
- Servo
