Name: AOC 24B3CF2 LED EEC E (A - G) 60.5 cm (23.8 inch) 1920 x 1080 p 16:9 1 ms HDMI™ IPS LED
Brand: AOC
SKU: 3402278

Highlights & Details

AOC 24B3CF2 LED

Screen size 60.5 cm (23.8 inch) Full HD, 1920 x 1080 p;Response time: 1 msEnergy efficiency rating (calc): E (A - G)
Interfaces: HDMI™;Height adjustable

Technical specifications

Screen size 60.5 cm (23.8")
Screen technology: LED
Contrast ratio 1300:1
Contrast ratio (dynamic): 20000000:1
0.2745 x 0.2745 mm pixel distance
Pixel density: 93 ppi
Market positioning: House
HDMI version: 1.4b
Tilt angle range -5 - 23°
Energy efficiency rating (SDR): E
Energy efficiency class (HDR): E

Product type: LED

Resolution (max.): 1920 x 1080 p

Screen size diagonal (cm): 60.5 cm

Screen size diagonal (inches): 23.8 inch

Screen size diagonal (inches): 24 inch

Image format: 16:9

Panel technology: IPS LED

Touchscreen (display): No

Frame rate: 100 Hz

Response time: 1 ms

Brightness: 250 cd/m²

Contrast ratio (dyn): 20000000 : 1

Static contrast ratio: 1300 : 1

Factory colour: Black

Interfaces: HDMI™

No. of HDMI ports: 1 x

Features: Height adjustable

Audio power (max.): 4 W

Inclination: -5/+23

Power consumption (standby): 0.5 W

Hor. viewing angle: 178°

Vertical viewing angle: 178°

HDR support: Yes

Width: 542.4 mm

Height: 469.9 mm

Depth: 223.8 mm

Weight: 4.56 kg

Power supply (details): 100 - 240 V

Dim: (L x W x H) 600 cm x 542.4 mm x 469.9 mm

Display size: 24 inch - 29 inch

Display type: In-plane switching

Range of uses: Office
Home

Display resolution mode: Full HD

: E (A - G)

Display: 60.5 cm (23.8 inch)

Screen resolution: Full HD (1920 x 1080 Pixel)

Display (cm): 60.5 cm

Power consumption (off): 0.3 W

Power consumption (ON): 30 W

Device depth (without stand): 44.6 mm

Length: 600 cm

Display resolution: 1920 x 1080 Pixel

Height (without base): 316.2 mm

Type: internal

: 100 x 100 mm

UKCA: yes

Eco badge reference: ENERGY STAR

Number of speakers: 2

Anti-glare screen: yes

Stand included: yes

Headphone out: yes

Weight (without stand): 3.04 kg

Width (without stand): 542.4 mm

Cable lock slot: yes

VESA mounting: yes

DDC/CI: yes

RMS rated power: 4 W

Built-in USB hub: yes

USB Type-A downstream ports quantity: 2

USB Type-C downstream ports quantity: 1

Headphone outputs: 1

Built-in speaker(s): yes

Adjustable height (max): 11 cm

Pivot: no

Haze rate: 25 %

sRGB coverage (typical): 102.5 %

Adobe RGB coverage: 87.8 %

On Screen Display (OSD): yes

USB Type-C DisplayPort Alternate Mode: yes

NTSC coverage (typical): 89.4 %

USB Power Delivery (USB PD): yes

AC (power) in: yes

Power adapter included: yes

HDMI cable length: 1.5 m

Flicker-free technology: yes

Low Blue Light technology: yes

Frameless design: yes

USB Power Delivery up to: 65 W

VESA Adaptive Sync support: yes

Energy consumption (SDR) per 1000 hours: 18 kWh

Energy consumption (HDR) per 1000 hours: 18 kWh

BT.2020 coverage: 59.5 %

Fast charging: yes

Mean time between failures (MTBF): 30000 h

HDMI: yes

HDCP: yes

Swivelling: no

Number of OSD languages: 19

Package weight: 7.04 kg

Plug and Play: yes

Built-in camera: no

Tilt adjustment: yes

Power consumption (max): 130 W

Detachable stand: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3402278 AOC 24B3CF2 LED EEC E (A - G) 60.5 cm (23.8 inch) 1920 x 1080 p 16:9 1 ms HDMI™ IPS LED

Description

Compact brilliance with USB-C connectivity and height-adjustable stands for more productivity

Introducing the latest addition to the B3 series – a brilliant 23.8-inch display with an IPS panel for stunning images and lifelike colors. If you are looking for a compact monitor, the 24B3CF2 is the ideal choice. Moreover, it offers USB-C, so that you can catch three birds with one stone. Video signal, power and data transfer are available via a single cable, WAS increases your productivity. This monitor has height-adjustable feet, which integrate ergonomic functions seamlessly in your workstation. The ability to adjust the height to suit your preferences allows you to achieve the perfect viewing angle, reducing the strain on the neck and eyes during longer work or learning sessions. No matter whether you are working or studying, you enjoy a comfortable and pleasant viewing experience with the compact screen size of the 24B3CF2.
