APC BV500I UPS 500 VA No. of outputs 6 x
EAN:
Part number:
Item no:
Highlights & Details
APC BV500I UPS 500 VA No. of outputs 6 x
- Ups with battery backup and surge protection for electronics and computers
- Output connections: (6) IEC 320 C13 (power failure protection)
- Nominal output voltage: 230V
- Nominal input voltage: 230V
- Input connection type: IEC-320 C14
Technical specifications
- Maximum configurable power (watts): 300 watts / 500 VA
- Output frequency (not synchronized): 50/60 +/- 1 Hz
- Topology: Line-Interactive
- Type of waveform: Gradual approach to a sine wave
- Transfer time: 6ms (typical)/ 10ms (max.)
- Input frequency: 50/60 Hz +/-5 Hz (automatic sampling)
- Battery type: Maintenance-free sealed lead-acid battery with suspended electrolyte: Leak-proof
- Expected battery life (in years): 3 - 5
- Control panel: LED status indicator for mains operation:battery operation
- Control panel: Alarm when battery is on: Specific low battery alarm: Overload alarm with continuous tone
- Operating temperature range 0-40°C.
- Operating relative humidity: 0-90%
- Noise level (1 meter distance): 40 dBA
- CE
- RoHS compliant
- Product type
UPS
- Nominal power
500 VA
- No. of outputs
6 x
- Output
IEC socket
- Type
BV500I
- Width
160 mm
- Height
92.5 mm
- Depth
305 mm
- Weight
3.9 kg
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2246661 APC BV500I UPS 500 VA No. of outputs 6 x
Warranty Terms
Warranty Terms 2246661 APC BV500I UPS 500 VA No. of outputs 6 x
Description
Automatic voltage regulation: Automatically increases the low voltage step by step and reduces the high voltage to levels suitable for your devices.
Wall mounting holes: Flexibility for installation in confined spaces; wall mounting or other surfaces.
Control - LED indicators: Clear displays for power quality, UPS and battery status.
Control - Warning Sounds - notifies users when the power or UPS system status changes.
Supports cold start: Allows temporary battery operation in the event of a power failure.
Sockets for connecting plug-in power supplies: Protect devices with input transformers without covering other sockets.
Slim design: The slim, modern housing can be positioned vertically or horizontally. Wall mounting is also possible. It fits in any technical environment or in private households.
Automatic voltage regulation (AVR) with boost function: Extends the service life and bridging time of batteries by correcting undervoltage without discharging the battery.
Safety - Approved by testing institutions: Ensures that the product has been tested and approved for safe operation with the connected devices of service providers and within the specified environment.
Powerful security features: Protect your Home UPS from overloads, mains surges, short-circuits, installation errors and battery damage due to under-voltages.
Battery failure notification: Early battery fault detection analyzes enable timely preventive maintenance.
Intelligent battery management: An intelligent precision charging system optimizes the performance, life and reliability of batteries.
Ups systems and surge protection: The outputs provide ample autonomy for network gateways and other important devices. Thus, even in the event of a power failure, the Internet access remains functional for several hours.
Outputs with battery buffer and overvoltage protection: Protect your hardware in case of power failures, overvoltages and voltage peaks.
This text is machine translated.
Wall mounting holes: Flexibility for installation in confined spaces; wall mounting or other surfaces.
Control - LED indicators: Clear displays for power quality, UPS and battery status.
Control - Warning Sounds - notifies users when the power or UPS system status changes.
Supports cold start: Allows temporary battery operation in the event of a power failure.
Sockets for connecting plug-in power supplies: Protect devices with input transformers without covering other sockets.
Slim design: The slim, modern housing can be positioned vertically or horizontally. Wall mounting is also possible. It fits in any technical environment or in private households.
Automatic voltage regulation (AVR) with boost function: Extends the service life and bridging time of batteries by correcting undervoltage without discharging the battery.
Safety - Approved by testing institutions: Ensures that the product has been tested and approved for safe operation with the connected devices of service providers and within the specified environment.
Powerful security features: Protect your Home UPS from overloads, mains surges, short-circuits, installation errors and battery damage due to under-voltages.
Battery failure notification: Early battery fault detection analyzes enable timely preventive maintenance.
Intelligent battery management: An intelligent precision charging system optimizes the performance, life and reliability of batteries.
Ups systems and surge protection: The outputs provide ample autonomy for network gateways and other important devices. Thus, even in the event of a power failure, the Internet access remains functional for several hours.
Outputs with battery buffer and overvoltage protection: Protect your hardware in case of power failures, overvoltages and voltage peaks.
This text is machine translated.
Scope of delivery
- Power cord (1.5 m)
- User manual
