APEM Q16P1GXXY220E LED indicator light Yellow 230 V AC
EAN:
Part number:
Item no:
Product type
LED indicator light
Operating voltage
230 V AC
Operating current
3 mA
Recess diameter
16 mm
IP rating
IP67
Datasheet (PDF)
Number
Total (€ 2.93 / piece)
€ 2.93
plus VAT.
14-day return policy included
Technical specifications
- Product type
LED indicator light
- Type
Q16 P1 GXXY220E
- Factory colour
Yellow
- Operating voltage
230 V AC
- Operating current
3 mA
- Recess diameter
16 mm
- Case colour
Grey
- Material
Brass
- Material properties
satin
- Mounting type
Screw and union
IP67
- LED features
splashproof
External reflector
- Connection
Type C CEE 7/16 plug 2.8 mm
- Dim
(Ø x L) 18.3 mm x 48.5 mm
- Length
48.5 mm
- (Ø)
18.3 mm
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 1296927 APEM Q16P1GXXY220E LED indicator light Yellow 230 V AC
User & Safety Instructions
User & Safety Instructions 1296927 APEM Q16P1GXXY220E LED indicator light Yellow 230 V AC
Description
Hints
The figure - please note the information in the technical data to color, color and reflector design with features as well as the data sheet of the manufacturer.
