APEM Q8R1CXXW24E LED indicator light White 24 V DC
EAN:
Part number:
Item no:
Product type
LED indicator light
Operating voltage
24 V DC
Operating current
20 mA
Recess diameter
8 mm
IP rating
IP67
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 6.29
5
6% = € 0.38
€ 5.91
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 6.29 / piece)
€ 6.29
plus VAT.
14-day return policy included
Technical specifications
- Product type
LED indicator light
- Type
Q8 R1 CXXW 24E
- Factory colour
White
- Operating voltage
24 V DC
- Operating current
20 mA
- Recess diameter
8 mm
- Case colour
Chrome
- Material
Brass
- Material properties
shiny
- Mounting type
Screw and union
IP67
- LED features
splashproof
Built-in reflector
- Connection
Type C CEE 7/16 plug 2.8 mm
- Dim
(Ø x L) 9.5 mm x 44.75 mm
- Length
44.75 mm
- (Ø)
9.5 mm
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 1296984 APEM Q8R1CXXW24E LED indicator light White 24 V DC
User & Safety Instructions
User & Safety Instructions 1296984 APEM Q8R1CXXW24E LED indicator light White 24 V DC
Description
Hints
The figure - please note the information in the technical data to color, color and reflector design with features as well as the data sheet of the manufacturer.
