Aratas 670946 TDR 1 pc(s) Time range: 0.1 - 432000 s
EAN:
Part number:
Item no:
Product type
TDR
Functions
On-delay
Off-delay
Single-shot leading-edge
Single-shot trailing-edge
Impulse ON through contact timer
Min. operating voltage
24 V AC
24 V DC
Max. operating voltage
230 V AC
48 V DC
Type
670946
Datasheet (PDF)
Technical specifications
- Product type
TDR
- Type
670946
- Connection
Screws
- Functions
On-delay
Off-delay
Single-shot leading-edge
Single-shot trailing-edge
Impulse ON through contact timer
- Min. operating voltage
24 V AC
24 V DC
- Max. operating voltage
230 V AC
48 V DC
- Operating voltage
24, 24 - 230, 48 V AC, V DC
- Time range (min.)
0.1 s
- Time range (max.)
432000 s
- Width
22.5 mm
- Height
79 mm
- Dim
(W x H) 22.5 mm x 79 mm
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3819203 Aratas 670946 TDR 1 pc(s) Time range: 0.1 - 432000 s
User & Safety Instructions
User & Safety Instructions 3819203 Aratas 670946 TDR 1 pc(s) Time range: 0.1 - 432000 s
Description
Timer relay 17.5mm wide, lockable, screw terminals- 8 multifunction, start input, 1 W- 0.1s..120h, SW: analogue specifications- 24..230VAC(50/60Hz)/24..48VDC- IP30, terminals IP20- UL, CSA, corresponds to EN61812-1
