Arctic P14 Pro Reverse PC fan Black
EAN:
Part number:
Item no:
Arctic P14 Pro Reverse PC fan
Highlights & Details
- The fan diameter of 140 mm provides for a strong air flow
- Supports speeds from 0 to 2650 rpm
- Fluid dynamic bearings for quiet operation
- Reversed wing design for versatile airflow options
- Daisy-chain compatible for easy connection of multiple fans
Technical specifications
- Fan diameter 14 cm
- Storage type: Fluid dynamic bearing (FDB)
- Fan connection 4-pin + 4-pin
- Product type
PC fan
- Fan size
140 mm
- Rotational speed (min.)
400 U/min
- Air discharge
166.5 m³/h
- Rotational speed (max.)
2650 U/min
- Type of bearing
Fluid dynamic bearing
- Connection
4-pin
- Factory colour
Black
- Weight
248 g
- Content
1 pc(s)
- Cable length
0.48 m
- Type
Fan
- UKCA
yes
- Number of screws
4
- Screws included
yes
- Operating temperature (T-T)
0 - 40 °C
- Fan dimensions (W x D x H)
140 x 140 x 30 mm
- Rated voltage
12 V
- Quantity per pack
1 Stück(e)
- Pulse-width modulation (PWM) support
yes
- Rated current
0.4 A
- Starting voltage
4 V
- Number of fan blades
5
- Package weight
285 g
- Maximum airflow
98 cfm
- Maximum air pressure
5.1 mmwc
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3730237 Arctic P14 Pro Reverse PC fan Black
Description
The Arctic P14 Pro reverse chassis fan was developed to improve the air flow and cooling performance in your system. With a fan diameter of 140 mm and a speed of 0 to 2650 rpm it provides an air throughput of 98 cfm and ensures optimum cooling performance even under high load. The hydrodynamic bearing of the fan provides for longevity and a low-noise operation, as a result of which the Ideal is suitable for both the gaming as well as the workstation configurations.
Thanks to its unique design with reverse wings and reversible air flow, the P14 Pro Reverse offers versatile installation options and adapts to different system configurations. In addition, the integration of a microcontroller and the support of pulse width modulation (PWM) enables precise control of the fan speed, whereby power and noise level are effectively balanced. Its Daisy-chain compatibility simplifies connections and simplifies the management of multiple fans in your system.
This text is machine translated.
Thanks to its unique design with reverse wings and reversible air flow, the P14 Pro Reverse offers versatile installation options and adapts to different system configurations. In addition, the integration of a microcontroller and the support of pulse width modulation (PWM) enables precise control of the fan speed, whereby power and noise level are effectively balanced. Its Daisy-chain compatibility simplifies connections and simplifies the management of multiple fans in your system.
