AS Schwabe 10030 Rubber flexible cable H07RN-F 5 x 2.5 mm² Black Sold per metre
EAN:
Part number:
Item no:
Product type
Rubber flexible cable
Cable type
H07RN-F
No. of leads
5 x
Cross section (each core)
2.5 mm²
No. of leads (part 2)
5 x
Datasheet (PDF)
Highlights & Details
as - Schwabe rubber hose cable 1 m, H07RN-F3G1.5, both sides smoothly cut, bound to the ring, 230 V / 16 A for industrial / construction site
- Application area: The connection with 230 V / 16 A offers Ideal for the application with construction site equipment & drills.
- Sustainable adapter management using high-quality materials.
- Also recommended for private use
Technical specifications
- Product type
Rubber flexible cable
- Cable type
H07RN-F
- No. of leads
5 x
- Cross section (each core)
2.5 mm²
- No. of leads (part 2)
5 x
- Cross section (each core) (part 2)
2.5 mm²
- Cross section
5 x 2.5 mm² + 5 x 2.5 mm²
- Cable features
Oil-resistant
- Factory colour
Black
- Outside Ø
17 mm
- Content
Sold per metre
- Nominal voltage
400 V
- Bend radius (no. of ODs for fixed installation)
6
- Sold per metre
Yes
- Manufacturer part #
10030
- Insulation material
Neoprene
- RoHS-compliant
Yes
- Min. temperature range (fixed installation)
-25 °C
- Max. temperature range (fixed installation)
60 °C
- Certification marks
DIN EN 50525-2-21; VDE 0285-525-2-21:2012-01:2012-01
- Type
10030
- Nominal current
16 A
Documents & Downloads
Datasheet
Datasheet 2890972 AS Schwabe 10030 Rubber flexible cable H07RN-F 5 x 2.5 mm² Black Sold per metre
User & Safety Instructions
User & Safety Instructions 2890972 AS Schwabe 10030 Rubber flexible cable H07RN-F 5 x 2.5 mm² Black Sold per metre
Description
The power line was tested according to current standards and certified with protection class IP44. Heavy rubber hose line for the necessary insulation. Approved for use in industry
RN-Rubber hose pipes made of rubber
The heavy rubber sheathed cables "RN-F" have rubber insulating sleeves and are encased in neoprene rubber. They are oil, UV and ozone resistant and are suitable for temperature ranges from -30°C to +60°C. Due to their good mechanical resistance they withstand high loads in dry and damp rooms as well as in water and can be used permanently outdoors, e.g. in agricultural holdings or on construction sites.
For over 38 years, as - Schwabe has been convincing with the highest quality in the electrical engineering sector.
as - Schwabe stands for Swabian precision, reliability and innovation.
This text is machine translated.
RN-Rubber hose pipes made of rubber
The heavy rubber sheathed cables "RN-F" have rubber insulating sleeves and are encased in neoprene rubber. They are oil, UV and ozone resistant and are suitable for temperature ranges from -30°C to +60°C. Due to their good mechanical resistance they withstand high loads in dry and damp rooms as well as in water and can be used permanently outdoors, e.g. in agricultural holdings or on construction sites.
For over 38 years, as - Schwabe has been convincing with the highest quality in the electrical engineering sector.
as - Schwabe stands for Swabian precision, reliability and innovation.
This text is machine translated.
Features
- Very simple installation with wire end sleeves.
- Also use our extension cable in agricultural holdings.
- Your replacement part for every commercially available drill
