ASRock EPYC4000D4U Motherboard PC base #####AMD AM5 Form factor (details) Micro-ATX
EAN:
Part number:
Item no:
ASRock EPYC4000D4U motherboard KNOLL3 X300 socket AM5 micro ATX
Highlights & Details
- AMD socket AM5 AMD EPYC 4004, AMD Ryzen 7000 series, AMD Ryzen 8000 series, AMD Ryzen 9000 series
- Server micro ATX KNOLL3 X300
- DDR5 SDRAM 4 DIMM RAM maximum: 48 GB
- SATA III
- ASPEED AST2600
- BIOS Type: UEFI AMI 256 Mbit ACPI Version: 6.4
- Gigabit Ethernet
- This text is machine translated.
Technical specifications
- Socket AM5
- Supported memory: DDR5 SDRAM
- Number of memory slot pins: 288
- ECC compatibility: ECC and non-ECC
- Motherboard chipset: KNOLL3 X300
- Motherboard form factor: Micro ATX
- Product type
Motherboard
- Form factor
Micro-ATX
#####AMD AM5
- Graphics card type
ASPEED
- Interfaces
Gigabit LAN (1 Gbps)
USB A (USB 3.1 1st gen)
DisplayPort
HDMI™
VGA
- No. of PCIe 3.0 x16
1 x
- No. of SATA III ports
2 x
- Depth
24.4 cm
- Width
24.4 cm
- No. of DisplayPort
1 x
- No. of HDMI ports
1 x
- No. of VGA ports
1 x
- No. of USB type A 3.1 / 3.2 1st Gen
2 x
- Onboard graphics card
Yes
- Operating voltage
1.1 V
- 10/100/1000 Mbps ports
2 x
- RAM / Max. upgrade
48 GB
- RAM type
DIMM
- Range of use
Server
- Wi-Fi
No
- UKCA
yes
- BIOS memory size
256 Mbit
- Operating temperature (T-T)
10 - 35 °C
- Serial ports quantity
1
- Ethernet LAN
yes
- Maximum number of SMP processors
1
- Number of memory slots
4
- ATX Power connector (24-pin)
yes
- TPM connector
yes
- Operating relative humidity (H-H)
20 - 90 %
- Storage temperature (T-T)
-40 - 70 °C
- IPMI LAN (RJ-45) port
yes
