ASRock Mini PC workstation Jupiter X300 2.5 cm (1 inch) 90BXG3Z01-A20GA0F
EAN:
Part number:
Item no:
Highlights & Details
ASRock Jupiter X300 2.5 cm (1 inch) Mini PC workstation
- Display: 2.5 cm (1 inch)
- DDR4 SDRAM
Technical specifications
- SSD form factor M.2
- Graphics card family: AMD
- AMD X300 motherboard chipset
- Socket AM4
- Panel-mounting interface 75 x 75.100 x 100 mm
- Product type: Mini PC Barebone
- Product type
Mini PC workstation
- Display (cm)
2.5 cm
- Screen size diagonal (inches)
1 inch
- CPU
- RAM type
DDR4 SDRAM
- RAM / Max. upgrade
64 GB
- Onboard graphics card
No
- HDD capacity (total)
0 GB
- Hard drive
0 GB
- Keyboard layout
None (PC-controlled)
- No. of DisplayPort
1 x
- No. of HDMI ports
1 x
- No. of USB A 2.0 ports
2 x
- No. of USB type A 3.1 / 3.2 1st Gen
4 x
- No. of VGA ports
1 x
- Factory colour
Black
- Width
178 mm
- Height
34 mm
- Depth
178 mm
- PSU power
90 W
- Display size
- 23 inch
- Display
2.5 cm (1 inch)
- 10/100/1000 Mbps ports
1 x
- Audio power (max.)
2 W
- Type
External AC adapter
- Wi-Fi
No
- UKCA
yes
- Number of speakers
1
- Ethernet LAN
yes
- Cable lock slot
yes
- VESA mounting
yes
- Number of memory slots
2
- Number of M.2 (M) slots
2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
2
- Headphone outputs
2
- Microphone in
yes
- DC-in jack
yes
- Built-in speaker(s)
yes
- Non-ECC
yes
- Number of power supply units
1
- Built-in processor
no
- Number of processors supported
1
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3730336 ASRock Mini PC workstation Jupiter X300 2.5 cm (1 inch) 90BXG3Z01-A20GA0F
Description
Hints
HDMI® is a registered trademark of HDMI Licensing LLC
Image may differ from actual product.
