ASSMANN WSW A-USB A-2P USB-built-in Bush 2.0 - Dual Port Socket, build-in USB A Socket, built-in TC-A-USB A-2P-203 USB A
EAN:
Part number:
Item no:
Product type
USB connector
Connector type
Socket, built-in
Connector standard
USB 2.0
Type
TC-A-USB A-2P-203
Type
90° PCB mounting
Datasheet (PDF)
Number
Total (€ 0.40 / piece)
€ 2.51
-84 %
€ 0.40
plus VAT.
14-day return policy included
Highlights & Details
ASSMANN WSW A-USB A-2P USB-built-in Bush 2.0 - Dual Port Socket, build-in USB A
Our service for you
Technical specifications
- Type
TC-A-USB A-2P-203
- Type
90° PCB mounting
- Product type
USB connector
- Connector type
Socket, built-in
- Type
USB A
- Connector standard
USB 2.0
- Connection
Solder
- Manufacturer part #
1586531
- Content
1 pc(s)
- RoHS-compliant
Yes
Documents & Downloads
Datasheet
Datasheet 1586531 ASSMANN WSW A-USB A-2P USB-built-in Bush 2.0 - Dual Port Socket, build-in USB A Socket, built-in TC-A-USB A-2P-203 USB A
User & Safety Instructions
User & Safety Instructions 1586531 ASSMANN WSW A-USB A-2P USB-built-in Bush 2.0 - Dual Port Socket, build-in USB A Socket, built-in TC-A-USB A-2P-203 USB A
Description
USB A socket for printed circuit boards · Solder version.
