Asus PRO WS W880-ACE Motherboard PC base #####Intel® 1851 Form factor (details) ATX Motherboard chipset Intel® W880
EAN:
Part number:
Item no:
Asus PRO WS W880-ACE Motherboard
Highlights & Details
- Supports Intel core 12 and 13 processors. Generation
- Equipped with high-definition audio via Realtek ALC1220P codec
- Provides comprehensive storage options with 8 x SATA-600 (RAID) and M.2 support
- Provides multiple connectivity options, including USB 3.2 Gen 2 and Thunderbolt 4
- With Asus Q-design for an easy installation of the components
Technical specifications
- Special features: Two-channel memory architecture, Intel extreme memory profiles (XMP)
- Max. Number Processors: 1
- Depth: 24.4 cm
- Width 30.5 cm
- Included cable 2 x Serial ATA cable
- Software included: Armoury Crate, Asus fan Xpert 4, Asus CPU-Z, Adobe Creative cloud (free trial version), Norton 360 Deluxe (60-day trial version), WinRAR, Asus control center express
- Audio Codec: Realtek ALC1220P
- Network interfaces 2 x 2.5 Gigabit Ethernet, Gigabit Ethernet
- Supported RAM Health Check: On-the-ECC, ECC
- Registered or buffered: Unbuffered, clock-independent, unbuffered
- Power connections: Main power connection, 24-pin, 2 8-pin ATX12V connections
- Internal interfaces: 1 x USB-C 3.2 Gen 2x2 - pin strip 2 x USB 3.2 Gen 1 - pin strip 4 x USB 2.0 - pin strip 1 x serial - pin strip 1 x audio - pin strip 1 x Thunderbolt 4 - pin strip
- Interface: 1 x HDA1 x VGA1 x Thunderbolt 41 x USB-C 3.2 Gen2x26 x USB 3.2 Gen 21 x LAN (Gigabit Ethernet)2 x LAN (2.5Gigabit Ethernet)1 x audio line out - Mini jack plug 1 x microphone - Mini jack plug
- Expansion slots: 1 x CPU4 x DIMM 288-pin 2 x PCIe 5.0 x16 (Dual x8-mode; single card: X16-mode)1 x PCIe 4.0 x16 (x4 mode)4 x M.2 socket (2280 M.2-slot)
- Product type
Motherboard
- Chipset
Intel® W880
#####Intel® 1851
- Form factor
ATX
- Processor/type
unterstützt Intel Core Ultra Prozessoren (Serie 2)
- RAM type
DDR5 RAM
- Clock speed
4533 MHz
- RAM / Max. upgrade
256 GB
- Interfaces
HDMI™
VGA
Thunderbolt 4
USB C®
USB A (USB 3.2 2nd gen)
USB A (USB 3.2 1st gen)
USB A (USB 2.0)
RJ45
Audio line out
- No. of DDR5 slots
4 x
- No. of Gigabit LANs
3 x
- No. of PCIe 3.0 x16
3 x
- No. of PCIe 3.0 x16
1 x
- No. of USB 2.0 ports
4 x
- No. of USB 3.2 2nd Gen (USB 3.1)
6 x
- No. of USB 3.2
2 x
- No. of USB 3.0 ports
4 x
- No. of SATA III ports
8 x
- No. of serial ports
1 x
- Onboard graphics
ASPEED AST2600
- Depth
300 mm
- Height
100 mm
- Width
300 mm
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3413735 Asus PRO WS W880-ACE Motherboard PC base #####Intel® 1851 Form factor (details) ATX Motherboard chipset Intel® W880
Description
The Asus Pro WS W880-ACE SE motherboard is designed for efficient high-performance computing. It supports Intel core 12 and 13 processors. Generation, allowing users to benefit from advanced processing capabilities. With four DIMM slots for DDR5 SDRAM, the memory speeds can be increased by overclocking to up to 4533 MHz. This motherboard comes with high-definition audio features provided by the Realtek ALC1220P codec to provide a high-quality audio experience in a variety of applications. For data management, it offers extensive storage options, including 8 x SATA-600 (RAID) and several M.2-sockets, as well as support for the Intel Rapid storage technology. The connectivity options include USB 3.2 Gen 2 and Thunderbolt 4 that enable fast data transfer. With advanced hardware features such as Asus Q design for easier installation and a robust BIOS interface for system management, the Asus Pro WS W880-ACE SE is tailor-made for enthusiasts and professionals who want to build a reliable and powerful workstation.
