ATEN ATEN CS1942DPA 2-Port USB 3.0 8K DP KVM, KVM changeover switch DisplayPort 7680 x 4320 Pixel
EAN:
Part number:
Item no:
Highlights & Details
ATEN ATEN CS1942DPA 2-Port USB 3.0 8K DP KVM, KVM changeover switch
- Black
- Number of computers: 2
- Keyboard Port type: USB Mouse port type: USB video Port type: DisplayPort
- 8K Ultra HD 7680 x 4320 pixels
- Direct current 3.18 W
Technical specifications
- USB-Plug USB Typ-A, USB Typ-B
- HD type 8K Ultra HD
- Power source: Direct current
- Factory colour
Black
- Depth
200 mm
- Height
43 mm
- Length
20.00 cm
- Width
71.8 mm
- Display resolution
7680 x 4320 Pixel
- Frame rate
240 Hz
- No. of DisplayPort
4 x
- Distributor/switch features
Steel casing
- Switch function
Key
- Video via
DisplayPort
- Ethernet ports
1
- Power consumption (ON)
3.18 W
- No. of switchable PCs
2 pc(s)
- Input voltage
12 V
- Video resolution
7680 x 4320 Pixel
- Weight
470 g
- UKCA
yes
- Push button
yes
- Operating temperature (T-T)
0 - 50 °C
- Storage relative humidity (H-H)
0 - 80 %
- Number of microphone inputs
4
- USB hub
yes
- Console USB ports quantity
2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity
2
- Headphone outputs
4
- DC-in jack
yes
- Number of computers controlled
2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity
2
- Video bandwidth
60 Hz
- Console DisplayPorts ports quantity
4
- Console RJ-45 ports quantity
1
- Rack mounting
no
- Quick installation guide
yes
- Operating relative humidity (H-H)
0 - 80 %
- Storage temperature (T-T)
-20 - 60 °C
- Built-in display
no
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3796796 ATEN ATEN CS1942DPA 2-Port USB 3.0 8K DP KVM, KVM changeover switch DisplayPort 7680 x 4320 Pixel
Description
Support advanced multi-screen workflows with a dual-screen 8K KVM switch for creative, financial and professional applications.
2 DisplayPort PCs, 2 DisplayPort monitors, one KVM console
The CS1942DPA is a 2-port KVM switch that lets you switch between projects easily on a desktop with two PCs and two screens. With a single keyboard and mouse you can keep your workplace tidy and at the same time simplify the control of two DisplayPort computers via two DisplayPort screens. Whether you're an expert looking for a way to make your daily office work more productive, whether you're a content creator or a hybrid employee, or you want an immersive entertainment environment, the CS1942DPA is undoubtedly the key to transforming your workspace.
Unleash your creativity with this multi-tasking KVM workstation:
● A flawless visual experience with up to 4K@120 and 8K@60
● ultra-wide image formats of 21:9 and 32:9 for an impressive viewing experience
● A dual-port USB 3.0 hub for sharing USB peripherals that supports data transfer rates up to 5 Gbps
● Compatibility with multiple systems, including Windows, MacOS, and Linux
This text is machine translated.
Features
- Up to 7680 × 4320 at 60 Hz, 5120 × 2880 at 60 Hz and 4096 × 2160 at 120 Hz
- Daisy-chain connectable quad-screen control by connecting two CS1942DPAs to manage up to two PCs and four screens with one keyboard and one mouse
- All DisplayPort-/USB-cable and power supply are included in the delivery for an easy installation
- Computer selection via push buttons, remote port selector, hotkeys, mouse, and RS-232 commands
