Auer Signalgeräte Buzzer B100520405.CO AUER Acoustic pulse 24 V DC 90 dB
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 16.80
3
5% = € 0.83
€ 15.97
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 16.80 / piece)
€ 16.80
plus VAT.
14-day return policy included
Highlights & Details
AUER signal devices M28 Mounted buzzer intermittent, BU2, Ø 28.5 mm
- Mounted buzzer with a large voltage range
- 90 dB sound pressure for universal application
- Sound pressure by means of rotary window continuously adjustable (up to approx. 10 dB)
- Sound art: Pulse tone
- Installation dimension 28.5 mm (M28)
Technical specifications
- Product type
Buzzer
- Series
BU
- Operating voltage
24 V DC
- Signal type
Acoustic pulse
IP54
- Case colour
Black
- Type
AUER
- Noise emission (max.)
90 dB
- Pitch
3000 Hz
- Max. temperature
70 °C
- Min. temperature
-30 °C
Documents & Downloads
Datasheet
Datasheet 1417466 Auer Signalgeräte Buzzer B100520405.CO AUER Acoustic pulse 24 V DC 90 dB
User & Safety Instructions
User & Safety Instructions 1417466 Auer Signalgeräte Buzzer B100520405.CO AUER Acoustic pulse 24 V DC 90 dB
Conformity certificate
Conformity certificate 1417466 Auer Signalgeräte Buzzer B100520405.CO AUER Acoustic pulse 24 V DC 90 dB
Description
Top Price/Performance: The loud standard mounted buzzer for fitting in the boring holes with 28.5 mm diameter impresses with its large voltage range. The volume of the pulse tone with up to 90 dB is adjusted continuously via the rotating window. With closed rotary window is the buzzer is approx. 10 dB quieter.
