Bachmann BM0022846 Power strip (w/o switch) Black
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Power FRAME flush-mounted socket strip 2xCEE7/3 1xUSB C/C 65 W 0.2 m...
- Built-in Power FRAME connection fields
- Power and data connection at work places
- Suitable for Germany, Austria, Netherlands
Technical specifications
- Product group: Socket strips
- Product type: Power FRAME installation fields
- Colour, black
- Length 0.2 m
- Number of socket pots: 2
- Socket type: Protective contact, CEE 7/3, type-F
- USB charger: Yes
- Number of USB ports: 2
- Connection plug: Installation connector
- Plug type Wieland GST18
- With increased protection against accidental contact: Yes
- Regional use: Germany, Austria, Netherlands
- Height: 44 mm
- Width: 52.5 mm
- Depth: 220 mm
- Weight: 450g
- Packaging height 80 mm
- Package width 70 mm
- Packaging depth 330 mm
- Package weight: 0,446 kg
- Gross weight: 0.446
- Product type
Power strip (w/o switch)
- Outlets
2
- Cable length
0.20 m
- Factory colour
Black
- Cable design
Round
- Version
Cable
- Cable use
C13/C14 appliances
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3797391 Bachmann BM0022846 Power strip (w/o switch) Black
User & Safety Instructions
User & Safety Instructions 3797391 Bachmann BM0022846 Power strip (w/o switch) Black
Description
Bachmann Power FRAME 2xCEE7/3 1xUSB BM0022846
<>Similar illustration.
Please pay attention to the technical data and the EAN of the product.
Manufacturer:Bachmann Name:Power FRAME 2xCEE7/3 1xUSB C/C 65W 0.2mType:BM0022846Housing shape:rectangular number of safety contact sockets CEE 0.2 .35 (type F):2With on/off switch:no Number of connections USB:2Overvoltage protection:16 35 AWire cross-section:5 mmblack With cover:no Material quality:Thermoplastic Surface protection: Type: 7/3°C Type of connection Type: Type of the internal circuit: 1.5°C Type of the internal connection<><>Bachmann Power FRAME 2xCEE7/3 1xUSB BM0022846: more details
Power FRAME socket strip,
2xCEE7/3 35° sockets black,
with increased contact protection,
<>with installation connector,
with Bachmann logo,
packed in carton EAN: 4057298227813
Supplied: Bachmann Power FRAME 2xCEE7/3 1xUSB C/C 65W 0.2m BM0022846, packaging unit: 1 pcs., EAN: 4057298227813
This text is machine translated.
Scope of delivery
- Bachmann Power FRAME 2 x CEE7/3
