BALLUFF BAM00LM Support bracket BAM00LM 1 pc(s)
EAN:
Part number:
Item no:
Product type
Support bracket
Type
BAM00LM
Content
1 pc(s)
Material
Brass
UKCA
not relevant
Datasheet (PDF)
Highlights & Details
Balluff BAM00LM magnetic sensor bracket
- Functional principle: BMF retaining bracket
- Ambient temperature -40...85 °C
- Use: For magnetic field sensors BMF 305
- Application: Pneumatic cylinder with integral groove
- Material nickel-plated brass
Technical specifications
- Main features:Application: Pneumatic cylinder with integral groove
- Functional principle: BMF retaining bracket
- Material nickel-plated brass
- Ambient temperature -40...85 °C
- Use: For magnetic field sensors BMF 305
- Additional features:
- Functional principle: BMF retaining bracket
- Scope of delivery: Fastening part|mounting bracket
- Use: For magnetic field sensors BMF 305
- Material: Brass
- Tightening torque 1.5 Nm
- Mounting size T-groove
- Ambient temperature -40...85 °C
- Tightening torque clamp screw 1.5 Nm
- Surface protection: Nickel-plated
- Application: Pneumatic cylinders with integral|groove
- Sensor mounting: Cylinder screw ISO 7984 M3x8-|A2|Cylinder screw DIN 1207 M3x8-|A2
- Mounting bracket: Cheese head screw ISO 4762 M3x4-|A2/cheese head screw ISO 1207|M3x4- A2
- Product type
Support bracket
- Type
BAM00LM
- Content
1 pc(s)
- Material
Brass
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3417917 BALLUFF BAM00LM Support bracket BAM00LM 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3417917 BALLUFF BAM00LM Support bracket BAM00LM 1 pc(s)
Description
Our sensor holders can be combined with the mounting system BMS. The high-quality sensor holders are designed and tested for Balluff magnetic field sensors. They are characterized by precision and durability. Functional principle=BMF retaining bracket, application=pneumatic cylinder with integral groove, use=for magnetic field sensors BMF 305, material=nickel-plated brass, ambient temperature=-40...85 °C
