Image similar
Image similar
BALLUFF BAM023R Square corner BAM023R 1 pc(s)
EAN:
Part number:
Item no:
Product type
Square corner
Type
BAM023R
Content
1 pc(s)
Length
3.70 mm
Width
10.00 mm
Datasheet (PDF)
Highlights & Details
Balluff BAM023R reflectors and reflective films
- Dimensions 10 x 3.7 mm
- Ambient temperature -20...60 °C
- Use: For optoelectronic reflection light barriers
- For optoelectronic laser reflection light barriers
- Design: Corner of the dice 0.9 mm
- Active area: 0.3 cm²
Technical specifications
- Main features:Dimension 10 x 3.7 mm
- Active area: 0.3 cm²
- Active surface, material: PMMA
- Design: Corner of the dice 0.9 mm
- Mounting: Adhesive
- Type of light: Non-polarized light, also for polarized light
- Ambient temperature -20...60 °C
- Use: For optoelectronic reflection light barriers
- For optoelectronic laser reflection light barriers
- Additional features:
- Design: Corner of the dice 0.9 mm
- Use: For optoelectronic|reflective light barriers|for optoelectronic laser|reflective light barriers
- Active surface, material: PMMA
- ABS casing material
- Product type
Square corner
- Type
BAM023R
- Content
1 pc(s)
- Length
3.70 mm
- Width
10.00 mm
- Enclosure material
Acrylonitrile butadiene styrene
- Material
PMMA
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3418037 BALLUFF BAM023R Square corner BAM023R 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3418037 BALLUFF BAM023R Square corner BAM023R 1 pc(s)
Description
The right reflector for every environment: Our round and square-shaped reflectors and reflective films are heat and chemical resistant. They are suitable for red light, white light, infrared and laser applications. Balluff reflectors are ideal for applications with BOS sensors. You can choose between different sizes and mounting options. Design=cube corner 0.9 mm, use=for optoelectronic reflection light barriers for optoelectronic laser reflection light barriers, dimensions=10 x 3.7 mm, active surface=0.3 cm2, ambient temperature=-20...60 °C, active surface, material=PMMA, Material=ABS, light type=non-polarized light, also for polarized light, mount=adhesive
