Barthelme 66000220 LED driver Constant voltage 240 W 0 mA - 10 A 24 V Overvoltage 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
66000220
- Constant voltage
- 24 V
- 0 mA - 10 A
Technical specifications
- Execution = staticSuitable for outdoor use = yesHousing=metal housing
- Product type
LED driver
- Type
Constant voltage
- Operating current
10 A
- Dim
(L x W x H) 244 x 71 x 38 mm
- Factory colour
Metal
- Output voltage (max.)
24 V
- Output voltage (min.)
24 V
- Max. output current
10 A
- Output current (max.) - rounded
10 A
- Operating voltage
277 V AC
- Protection class
II
- LED driver features
Overvoltage
IP67
- Max. power
240 W
- No. of outputs
1 x
- No. of inputs
1 x
- Output current (min.)
0 mA
- Input voltage (max.)
431 V
- Min. input voltage
100 V
- Weight
0
- Power (min.)
0 W
- Power range
0 up to 240 W
- Width
71 mm
- Height
38 mm
- Length
244 mm
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2749433 Barthelme 66000220 LED driver Constant voltage 240 W 0 mA - 10 A 24 V Overvoltage 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2749433 Barthelme 66000220 LED driver Constant voltage 240 W 0 mA - 10 A 24 V Overvoltage 1 pc(s)
Description
Input: AC 2.2A/115VAC, 1.5A/230VAC, inrush current: 60A/230VAC, leakage current: ≪gt/>0.75mA/277VAC, no-load/standby power consumption: ≪gt/>0.5W, Overload 95-108%, degree of protection: Power down, recovery after troubleshooting, short circuit: Protection: Power down, recovery after troubleshooting, Overvoltage 28-34V, overvoltage+overheating: Power-off, recovery after fault-correction or temperature drop
This text is machine translated.
This text is machine translated.
Features
- Input: Alternating current: 2.2A/115VAC1.5A/230VACSwitch-on current 60A/230VACLeakage current: Less than 0.75mA/277VACIdle/standby power consumption: Less than 0.5WOverload 95-108%Protection type: Switch-offRestore after troubleshootingShort circuit: Protection type: Switch-offRestore after troubleshootingOvervoltage 28-34VOvervoltage and overheating: Switch-offRestoration after troubleshooting or after temperature has fallen
Scope of delivery
- Barthelme power supply 230V/24VDC 240W IP67 66000220
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
