Barthelme 66002200 Power supply unit 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Height: 39.5 mm
- Width 68 mm
- Design: Static
- Protection class (IP) IP67
- Suitable for outside use: Yes
- Protection class: II
- Length: 195 mm
- Output power 0..200 W
- Constant luminous flux regulation: No.
- Dimmer 0-10 V: No
- Dimmer 1-10 V: No
- DALI dimming: No.
- Dimmer DMX: No
- Dimmer DSI: No.
- Dimmer potentiometer (built-in): No.
- Dimming LineSwitch: No.
- Manufacturer-specific dimming: Yes
- Mains voltage modulation dimming: No.
- Dimming Phase section: No.
- Dimming leading edge: No.
- Dimming programmable: No.
- Dim. RF: No.
- Dimming Sine Wave Reduction: No.
- Dimming Touch and Dim: No.
- Zigbee dimming: No.
- Dimming with push-button: No.
- Without dimmer function: No.
- 08300 mA output current
- Output voltage 24 V
- Housing: Plastic housing
- Suitable for constant current: No.
- Suitable for constant voltage: Yes
- Suitable for DC voltage (primary side): Yes
- Product type
Power supply unit
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3551247 Barthelme 66002200 Power supply unit 1 pc(s)
Description
Input voltage range: 100-305 VAC, 2-pin, IP67, furniture ready, CASAMBI function, Efficiency 93%, protection against over-voltage, overload, overheating and short circuit
