Name: Beltrona INR21700-48GHBG Non-standard battery (rechargeable) 21700 Z solder tab Li-ion 3.6 V 4.8 Ah 1 pc(s)
Brand: Beltrona
SKU: 3768045

Large roll of light blue material wrapped in beige paper, shown on a white background.

Image similar

Datasheet (PDF)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Samsung INR21700-48G mit Z-Soldering tag Li-Ionen 3.6V / 4.8Ah

Enormous capacity: True 4,800 mAh for maximum run time in devices.
Reliable brand quality: First-class production quality from Samsung SDI for high cycle strength.
High energy density: Compact dimensions of the 21700-format used optimally.

Technical specifications

Size: 21700

Product type: Non-standard battery (rechargeable)

Technology: Li-ion

Dim: (Ø x H) 21.25 mm x 70.8 mm

Voltage: 3.6 V

Capacity (mAh, Ah): 4.8 Ah

Special-purpose battery features: Z solder tab

Max. charge voltage: 4.2 V

Max. charging current: 4.8 A

Terminal voltage: 2.5 V

Discharge current (max.): 9.6 A

Continuous discharge: 9.6 A

Min. temperature: -20 °C

Max. temperature: 60 °C

Height: 70.8 mm

(Ø): 21.25 mm

Weight: 70 g

Content: 1 pc(s)

Type: INR21700-48GHBG

Rechargeable: Yes

Integrated surge protection: No

Documents & Downloads

Datasheet

Datasheet 3768045 Beltrona INR21700-48GHBG Non-standard battery (rechargeable) 21700 Z solder tab Li-ion 3.6 V 4.8 Ah 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3768045 Beltrona INR21700-48GHBG Non-standard battery (rechargeable) 21700 Z solder tab Li-ion 3.6 V 4.8 Ah 1 pc(s)

Description

The Samsung INR21700-48G with Z-soldering tag is the perfect choice for applications where maximum endurance is required. With an impressive capacity of 4,800 mAh, this industrial quality cell provides long-lasting energy for E-bikes, energy storage systems or LED torches with moderate power consumption. Rely on longevity and constant power from the market leader.

This text is machine translated.
