Name: Beltrona INR21700-50SHBG Non-standard battery (rechargeable) 21700 Z solder tab Li-ion 3.6 V 5 Ah 1 pc(s)
Brand: Beltrona
SKU: 3768044

Roll of translucent plastic film in a cardboard dispenser, shown on a white background.

Image similar

Datasheet (PDF)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Samsung INR21700-50S with Z soldering tag Li-Ion 3.6V / 5.0Ah

Enormous capacity of 5000 mAh combined with extremely high current carrying capacity (up to 45 A).
Ideal for power-hungry applications such as e-cigarettes, tools and e-mobility.
Excellent cycle stability and stable voltage situation under load.

Technical specifications

Charging procedure CC-CV (constant current - constant voltage)

Size: 21700

Product type: Non-standard battery (rechargeable)

Technology: Li-ion

Dim: (Ø x H) 21.25 mm x 70.15 mm

Voltage: 3.6 V

Capacity (mAh, Ah): 5 Ah

Special-purpose battery features: Z solder tab

Max. charge voltage: 4.2 V

Max. charging current: 6 A

Terminal voltage: 2.5 V

Discharge current (max.): 45 A

Continuous discharge: 25 A

Min. temperature: -20 °C

Max. temperature: 80 °C

Height: 70.15 mm

(Ø): 21.25 mm

Weight: 72

Content: 1 pc(s)

Type: INR21700-50SHBG

Rechargeable: Yes

Integrated surge protection: No

Documents & Downloads

Datasheet

Datasheet 3768044 Beltrona INR21700-50SHBG Non-standard battery (rechargeable) 21700 Z solder tab Li-ion 3.6 V 5 Ah 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3768044 Beltrona INR21700-50SHBG Non-standard battery (rechargeable) 21700 Z solder tab Li-ion 3.6 V 5 Ah 1 pc(s)

Description

The Samsung INR21700-50S with Z soldering tag sets new standards in the 21700-class. It combines a maximum capacity of 5000 mAh with an impressive continuous current output of up to 25 A (without temperature monitoring) or 45 A (with temperature monitoring at 80 °C). The perfect choice for all, who do not want to make any compromises between runtime and Power.

This text is machine translated.
