Name: Beltrona MURUS18650VTC5HBG Non-standard battery (rechargeable) 18650 Z solder tab Li-ion 3.6 V 2.6 Ah 1 pc(s)
Brand: Beltrona
SKU: 3768054

A large roll of light gray adhesive or protective film on a cardboard core, with the loose end folded back on both sides.<br>

Image similar

Datasheet (PDF)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Murata US18650VTC5 with Z soldering tag Li-Ion 3.6V / 2.6Ah

Extremely high discharge current of up to 30A (with temperature monitoring)
Outstanding thermal stability and security thanks to reliable industrial quality
Long-lasting and cycle-resistant with high power output

Technical specifications

Charging procedure CC-CV (constant current - constant voltage)

Size: 18650

Product type: Non-standard battery (rechargeable)

Technology: Li-ion

Dim: (Ø x H) 18.35 mm x 65.1 mm

Voltage: 3.6 V

Capacity (mAh, Ah): 2.6 Ah

Special-purpose battery features: Z solder tab

Max. charge voltage: 4.2 V

Max. charging current: 2.5 A

Terminal voltage: 2.5 V

Discharge current (max.): 30 A

Continuous discharge: 20 A

Min. temperature: -20 °C

Max. temperature: 60 °C

Height: 65.1 mm

(Ø): 18.35 mm

Weight: 44.3 g

Content: 1 pc(s)

Type: MURUS18650VTC5HBG

Rechargeable: Yes

Integrated surge protection: No

Documents & Downloads

Datasheet

Datasheet 3768054 Beltrona MURUS18650VTC5HBG Non-standard battery (rechargeable) 18650 Z solder tab Li-ion 3.6 V 2.6 Ah 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3768054 Beltrona MURUS18650VTC5HBG Non-standard battery (rechargeable) 18650 Z solder tab Li-ion 3.6 V 2.6 Ah 1 pc(s)

Description

The Murata US18650VTC5 with Z soldering tag is a high-current high-drain cell of the top class. With a capacity of 2600 mAh and a constant discharge current of up to 20A (or 30A at shutdown at 80°C), it is perfectly suitable for demanding applications in power tools, modeling or for E-mobility.

This text is machine translated.
