Name: Beltrona NCR18650PF Non-standard battery (rechargeable) 18650 Z solder tab Li-ion 3.7 V 2.9 Ah 1 pc(s)
Brand: Beltrona
SKU: 3768049

A large roll of gray adhesive material on a cardboard core, with the backing partially peeled back on both ends.

Image similar

Datasheet (PDF)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Panasonic NCR18650PF with Z soldering tag LiNiCoAl 3.7V / 2.9Ah

High current carrying capacity: Up to 10 A continuous discharge current with stable 2900 mAh capacity.
Proven quality: Original Panasonic cell, Ideal for electric bikes, tools and sophisticated LED torches.
Reliable chemistry: Lithium nickel cobalt aluminum oxide (NCA) for optimum energy density and durability.

Technical specifications

Charging procedure CC-CV (constant current - constant voltage)

Size: 18650

Product type: Non-standard battery (rechargeable)

Technology: Li-ion

Dim: (Ø x H) 18.4 mm x 65.5 mm

Voltage: 3.7 V

Capacity (mAh, Ah): 2.9 Ah

Special-purpose battery features: Z solder tab

Max. charge voltage: 4.2

Max. charging current: 1375 mA

Terminal voltage: 2.5 V

Discharge current (max.): 10 mA

Continuous discharge: 10

Min. temperature: -20 °C

Max. temperature: 60 °C

Height: 65.5 mm

(Ø): 18.4 mm

Weight: 46.5 g

Content: 1 pc(s)

Type: NCR18650PF

Rechargeable: Yes

Integrated surge protection: No

Documents & Downloads

Datasheet

Datasheet 3768049 Beltrona NCR18650PF Non-standard battery (rechargeable) 18650 Z solder tab Li-ion 3.7 V 2.9 Ah 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3768049 Beltrona NCR18650PF Non-standard battery (rechargeable) 18650 Z solder tab Li-ion 3.7 V 2.9 Ah 1 pc(s)

Description

The Panasonic NCR18650PF with Z soldering tag is the perfect all-rounder when both stamina and power are required. With a capacity of 2900 mAh and a maximum continuous discharge current of 10 A, this unprotected industrial cell provides constant power for power-hungry applications - from electrical tools to E-Mobility battery packs.

This text is machine translated.
