Name: Beltrona PANNCR26650AHBG Non-standard battery (rechargeable) 26650 Z solder tab Li-ion 3.7 V 5 Ah 1 pc(s)
Brand: Beltrona
SKU: 3768048

Roll of light blue protective film with cardboard end caps on a white background.

Image similar

Datasheet (PDF)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Panasonic NCR26650A with Z soldering tag Li-Ion 3.7V/5.0Ah

Huge capacity of 5000 mAh for extra long running times
Proven premium quality from Panasonic
High cycle stability with up to 500 charge cycles
Stable voltage situation even under continuous load

Technical specifications

Charging procedure CC-CV (constant current - constant voltage)

Size: 26650

Product type: Non-standard battery (rechargeable)

Technology: Li-ion

Dim: (Ø x H) 26.5 mm x 65.3 mm

Voltage: 3.7 V

Capacity (mAh, Ah): 5 Ah

Special-purpose battery features: Z solder tab

Max. charge voltage: 4.2 V

Max. charging current: 3.4 A

Terminal voltage: 2.5 V

Discharge current (max.): 10 A

Continuous discharge: 5.5 A

Min. temperature: -20 °C

Max. temperature: 60 °C

Height: 65.3 mm

(Ø): 26.5 mm

Weight: 98 g

Content: 1 pc(s)

Type: PANNCR26650AHBG

Rechargeable: Yes

Integrated surge protection: No

Documents & Downloads

Datasheet

Datasheet 3768048 Beltrona PANNCR26650AHBG Non-standard battery (rechargeable) 26650 Z solder tab Li-ion 3.7 V 5 Ah 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3768048 Beltrona PANNCR26650AHBG Non-standard battery (rechargeable) 26650 Z solder tab Li-ion 3.7 V 5 Ah 1 pc(s)

Description

The NCR26650A Panasonic with Z soldering tag is the ideal energy source for applications where maximum durability is required. With an impressive capacity of 5000 mAh, this industrial quality cell provides reliable and long-lasting power for high-Power torches, E-mobility or demanding DIY battery packs.
