Name: Beltrona SAMINR18650-35EHBG Non-standard battery (rechargeable) 18650 Z solder tab Li-ion 3.6 V 3.5 Ah 1 pc(s)
Brand: Beltrona
SKU: 3768041

Roll of silver reflective film with cardboard ends on a white background, shown partially unwrapped.

Image similar

Datasheet (PDF)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Samsung INR18650-35E with Z soldering tag

Maximum capacity: Rich 3,500 mAh for extremely long running times.
Reliable brand quality: Original Samsung SDI quality cell with high cycle strength.
High continuous discharge current: Delivers up to 8 A constant for demanding applications.

Technical specifications

Charging procedure CC-CV (constant current - constant voltage)

Size: 18650

Product type: Non-standard battery (rechargeable)

Technology: Li-ion

Dim: (Ø x H) 18.55 mm x 65.3 mm

Voltage: 3.6 V

Capacity (mAh, Ah): 3.5 Ah

Special-purpose battery features: Z solder tab

Max. charge voltage: 4.2 V

Max. charging current: 3.5 A

Terminal voltage: 2.5 V

Discharge current (max.): 13 A

Continuous discharge: 8 A

Min. temperature: -20 °C

Max. temperature: 60 °C

Height: 65.3 mm

(Ø): 18.55 mm

Weight: 48 g

Content: 1 pc(s)

Type: SAMINR18650-35EHBG

Rechargeable: Yes

Integrated surge protection: No

Documents & Downloads

Datasheet

Datasheet 3768041 Beltrona SAMINR18650-35EHBG Non-standard battery (rechargeable) 18650 Z solder tab Li-ion 3.6 V 3.5 Ah 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3768041 Beltrona SAMINR18650-35EHBG Non-standard battery (rechargeable) 18650 Z solder tab Li-ion 3.6 V 3.5 Ah 1 pc(s)

Description

The Samsung INR18650-35E is the perfect choice for all applications, which depend on maximum durability. With an impressive capacity of 3,500 mAh and a stable current output of up to 8 A, this high-quality unprotected cell Ideal is suitable for electric bikes, torches, power banks and modeling.

This text is machine translated.
