Name: Beltrona SAMINR21700-50GBHBG Non-standard battery (rechargeable) 21700 Z solder tab Li-ion 3.6 V 4.9 Ah 1 pc(s)
Brand: Beltrona
SKU: 3768043

A large roll of light blue paper or film in a cardboard core, partially wrapped in protective packaging.

Image similar

Datasheet (PDF)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Samsung INR21700-50GB with Z soldering tag Li-Ion 3.6V / 4.9Ah

Huge capacity of 5,000 mAh for maximum running times.
Reliable brand quality from Samsung for demanding applications.
Constant power even at high capacity density

Technical specifications

Charging procedure CC-CV (constant current - constant voltage)

Size: 21700

Product type: Non-standard battery (rechargeable)

Technology: Li-ion

Dim: (Ø x H) 21.25 mm x 70.15 mm

Voltage: 3.6 V

Capacity (mAh, Ah): 4.9 Ah

Special-purpose battery features: Z solder tab

Max. charge voltage: 4.2 V

Max. charging current: 4850 mA

Terminal voltage: 2.5 V

Discharge current (max.): 14.55 A

Continuous discharge: 9.7 A

Min. temperature: -20 °C

Max. temperature: 60 °C

Height: 70.15 mm

(Ø): 21.25 mm

Content: 1 pc(s)

Type: SAMINR21700-50GBHBG

Rechargeable: Yes

Integrated surge protection: No

Documents & Downloads

Datasheet

Datasheet 3768043 Beltrona SAMINR21700-50GBHBG Non-standard battery (rechargeable) 21700 Z solder tab Li-ion 3.6 V 4.9 Ah 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3768043 Beltrona SAMINR21700-50GBHBG Non-standard battery (rechargeable) 21700 Z solder tab Li-ion 3.6 V 4.9 Ah 1 pc(s)

Description

The Samsung INR21700-50GB with Z-soldering tag sets new standards in terms of energy efficiency. With an impressive capacity of 5,000 mAh, this high-capacity cell is the perfect choice for E-mobility, powerful torches, power banks and all projects, which depend on every milliampere hour. Rely on long-life and proven Samsung quality.
