Image similar
Image similar
BERNSTEIN 6083000229 IN65-U1Z DGHK Door-operated switch 240 V AC 5 A Actuator wheel IP66/IP67 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 39.82 / piece)
€ 39.82
plus VAT.
Only 9 Piece(s) available
Highlights & Details
Insulated position switches
- Modular design
- Folding snap-in lid
- Protection class IP66 and IP67
- Metal actuator catch
- Metal fixing clamp
- Standard switch according to DIN EN 50047
- Highest reliability at low currents (1 mA)
- Tool-free rotation and Replacement Of the actuator
Technical specifications
- Product type
Door-operated switch
- Connection
Screws
- Operation type
Actuator wheel
- Switching voltage
240 V AC
- Switching current (max.)
5 A
- Contact type
2 breakers
- Contact opening
Quick-action switch
- Min. temperature
-30 °C
- Max. temperature
+75 °C
IP66/IP67
- Durability
30 x 106 switching cycles
- Material
Thermoplastic
- Width
31 mm
- Type
IN65-U1Z DGHK
- Content
1 pc(s)
- Dim
(L x W x H) 105.5 x 31 x 30.3 mm
- Height
30.3 mm
- Length
105.5 mm
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2179745 BERNSTEIN 6083000229 IN65-U1Z DGHK Door-operated switch 240 V AC 5 A Actuator wheel IP66/IP67 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2179745 BERNSTEIN 6083000229 IN65-U1Z DGHK Door-operated switch 240 V AC 5 A Actuator wheel IP66/IP67 1 pc(s)
Description
The IN62 and IN65 series are standard switches according to DIN EN 50047. Due to their dimensions as well as the variety of contacts and actuators, the switches can be used in almost any industrial application for safe position monitoring. The metal actuator catch and mounting clamp make the product particularly robust and powerful. The series optimally combines the economic advantages of a plastic switch with the robustness of a metal switch.
