binder 09 0124 320 06 Mini DIN connector Sleeve socket Total number of pins: 6 1 pc(s)
EAN:
Part number:
Item no:
Product type
Mini DIN connector
Connector type
Sleeve socket
Total no. of pins
6
Connection
Open end cable
Content
1 pc(s)
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 18.48
3
5% = € 0.92
€ 17.56
Volume discounts vary depending on the seller
You save € 0.00
Total (€ 18.48 / piece)
€ 18.48
plus VAT.
14-day return policy included
Technical specifications
- Type
09 0124 320 06
- Product type
Mini DIN connector
- Connector type
Sleeve socket
- Total no. of pins
6
- Connection
Open end cable
- Content
1 pc(s)
- Max. temperature
+85 °C
- Nominal current
5 A
- Min. temperature
-30 °C
- Nominal current - rounded value
5 A
- Seal
Screws
- Leading contact (PE)
No
- Nominal voltage
300 V
- Contact material
CuSn
- Case material
PBT, UL94V-0
22
- Connection angle
180°
- Manufacturer part #
09 0124 320 06
- Number of pins
6
IP67
Documents & Downloads
Datasheet
Datasheet 1663644 binder 09 0124 320 06 Mini DIN connector Sleeve socket Total number of pins: 6 1 pc(s)
