binder 09 0688 700 03 Mini DIN connector Socket, built-in Total number of pins: 2 1 pc(s)
EAN:
Part number:
Item no:
Product type
Mini DIN connector
Connector type
Socket, built-in
Total no. of pins
2
Connection
Open end cable
Content
1 pc(s)
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 17.64
3
5% = € 0.88
€ 16.76
Volume discounts vary depending on the seller
You save € 0.00
Total (€ 17.64 / piece)
€ 19.32
-9 %
€ 17.64
plus VAT.
14-day return policy included
Technical specifications
- Type
Binder
- Product type
Mini DIN connector
- Connector type
Socket, built-in
- Total no. of pins
2
- Connection
Open end cable
- Content
1 pc(s)
- Max. temperature
+85 °C
- Nominal current
16 A
- Min. temperature
-40 °C
- Nominal current - rounded value
16 A
- Seal
Screws
- Nominal voltage
630 V
- Contact material
CuSn
- Case material
PA
16
- Connection angle
180°
- Manufacturer part #
09 0688 700 03
- Number of pins
2
- Min. cross section
1.38 mm²
- Cross-section range
1.38 mm² (min)
- Feature
S-coded
IP68
Documents & Downloads
Datasheet
Datasheet 1664631 binder 09 0688 700 03 Mini DIN connector Socket, built-in Total number of pins: 2 1 pc(s)
