binder 09-0978-00-03 Subminiature Round Plug-in Connector Series Nominal current (details): 4 A
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 8.39
3
6% = € 0.47
€ 7.92
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 8.39 / piece)
€
Highlights & Details
binder 09-0978-00-03 Subminiature Round Plug-in Connector Series Nominal current (details): 4 A
- IP40
Technical specifications
- Connector type
Socket, built-in
- Total no. of pins
3
- Connection
Soldering
- Content
1 pc(s)
- Max. temperature
+125 °C
- Nominal current
4 A
- Min. temperature
-55 °C
- Nominal current - rounded value
4 A
- Seal
bayonet
- Nominal voltage
125 V
- Contact material
Au (gold)
- Cable Ø range
- Cross-section range
0.25 mm² (max)
IP40
- Series
710
- Manufacturer part #
09-0978-00-03
- Type
09-0978-00-03
- Type
Flange plug
- max. cross section
0.25 mm²
- Number of pins
3
- Nominal voltage (details)
125 V
- Nominal current (details)
4 A
- Contamination level
1
- Connection angle
180°
- Cross section
0.25 mm²
24
- Connection
Soldering
- Mounting hole diameter
M10 x 0.75
- Temperature range
- 40 - 85 °C
- RoHS-compliant
- Product type
Bullet connector
Documents & Downloads
Datasheet
Datasheet 738929 binder 09-0978-00-03 Subminiature Round Plug-in Connector Series Nominal current (details): 4 A
User & Safety Instructions
User & Safety Instructions 738929 binder 09-0978-00-03 Subminiature Round Plug-in Connector Series Nominal current (details): 4 A
Information
Information 738929 binder 09-0978-00-03 Subminiature Round Plug-in Connector Series Nominal current (details): 4 A
Description
· Connectors are used from the front to the panel section and screwed from behind
· Fixing with hexagon nut.
· Fixing with hexagon nut.
