binder 99 0710 03 05-20 Junction box Socket, straight Total number of pins: 5 + PE Series (round connectors): 694 1 pc(s
EAN:
Part number:
Item no:
Product type
Junction box
Connector type
Socket, straight
Total no. of pins
5 + PE
Connection
Screw terminal
Content
1 pc(s)
Datasheet (PDF)
Highlights & Details
99 0710 03 05 Series 694
- RD30 cable socket
- Number of pins 4+PE
- 14.0 - 18.0 mm
- unshielded
- screw terminal
- IP65
- ESTI+
- VDE
Technical specifications
- EMC-suitability: Unshielded
- Insulation resistance: ≥ 10¹⁰ Ω
- Continuous resistance ≤ 5 mΩ
- Insulation class III
- Over voltage category III
- Pollution level 3
- Material of contact body PA (UL94 HB)
- Cable diameter 14.0 - 18.0 mm
- Mounting type: Cable mounting
- Type
99 0710 03 05
- Product type
Junction box
- Connector type
Socket, straight
- Total no. of pins
5 + PE
- Connection
Screw terminal
- Content
1 pc(s)
- Nominal current
20 A
- Nominal current - rounded value
20 A
- Seal
screws
- Leading contact (PE)
Yes
- Nominal voltage
400 V
- Contact material
CuSn
- Case material
PA
AWG 14
- Manufacturer part #
99 0710 03 05-20
- Number of pins
5
- max. cross section
2.50 mm²
- Cross-section range
2.50 mm² (max)
- RoHS-compliant
Yes
IP65
- Series
694
Documents & Downloads
Datasheet
Datasheet 3215858 binder 99 0710 03 05-20 Junction box Socket, straight Total number of pins: 5 + PE Series (round connectors): 694 1 pc(s
User & Safety Instructions
User & Safety Instructions 3215858 binder 99 0710 03 05-20 Junction box Socket, straight Total number of pins: 5 + PE Series (round connectors): 694 1 pc(s
Description
Our range of power connectors is suitable for virtually any low and high voltage application, from safety and CCTV systems to fieldbus Ethernet components to AC and DC motors. Some models meet the needs of extreme environments, both indoors and outdoors. A variety of connection options are available, as locking systems bayonet, M23, M25 and RD24 locking are possible. Some models are ESTI+, UL and VDE approved. To extend the range of applications, users can choose between straight and right angle cable and flange versions.
Properties:
• 3 to 24 contacts, also with +PE
• Protection class of IP40 to IP69K
• UL, VDE and ESTI+ approval
• Cable and flange formats
• Solder, screw, crimp and molded cable
• Shieldable versions
This text is machine translated.
Properties:
• 3 to 24 contacts, also with +PE
• Protection class of IP40 to IP69K
• UL, VDE and ESTI+ approval
• Cable and flange formats
• Solder, screw, crimp and molded cable
• Shieldable versions
This text is machine translated.
