Image similar
BKL Electronic 10120116 Pin connector + strain relief Contact spacing: 2.54 mm Total number of pins: 34 No. of rows: 2 1
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
3
-
€ 1.25
9
8% = € 0.10
€ 1.15
15
11% = € 0.14
€ 1.11
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 3
Total (€ 1.25 / piece)
€
Highlights & Details
Pole connector
- Gold-plated
- DIN 41651
Technical specifications
- Gold-plated contacts
- DIN 41 651
- Also for double-row multi-pin connectors.
- Connector type
Power strip
- Features
+ strain relief
- CS
2.54 mm
- No. of rows
2
- Pins per row
17
- Total number of pins
34
- Nominal voltage
500 V AC
- Nominal current
1 A
- Contact material
Phosphorus bronze
- Content
1 pc(s)
- Connection
Cut & Clip
- Type
10120116
- Dim
(L x W x H) 6.9 x 47.86 x 15.6 mm
- Factory colour
Black
- Height
15.6 mm
- Length
6.9 mm
- Width
47.86 mm
- Connector contact surface
Brass
- Board contact surface
Brass
- Manufacturer part #
10120116
- Type
With strain relief
- Pins
2 x 17
- Casing
Glass-fibre reinforced polyester
- RoHS-compliant
Yes
- Max. temperature
+105 °C
- Min. temperature
-40 °C
- Product type
Pin connector
Variants(All information is without VAT, plus shipping costs)
Pins
BKL Electronic 10120116 Pin connector + strain relief Contact spacing: 2.54 mm Total number of pins: 34 No. of rows: 2 1 pc(s)
This article
2 x 17
Minimum order quantity: 3
Multiple: 1
€ 1.25*
BKL Electronic 10120862 Pin connector + strain relief Contact spacing: 2.54 mm Total number of pins: 6 No. of rows: 2 1 pc(s)
2 x 3 mm
Minimum order quantity: 3
Multiple: 1
€ 1.50*
BKL Electronic 10120864 Pin connector + strain relief Contact spacing: 2.54 mm Total number of pins: 8 No. of rows: 2 1 pc(s)
2 x 4
Minimum order quantity: 3
Multiple: 1
€ 1.50*
BKL Electronic 10120111 Pin connector + strain relief Contact spacing: 2.54 mm Total number of pins: 10 No. of rows: 2 1 pc(s)
2 x 5
Minimum order quantity: 5
Multiple: 1
€ 0.70*
BKL Electronic 10120112 Pin connector + strain relief Contact spacing: 2.54 mm Total number of pins: 14 No. of rows: 2 1 pc(s)
2 x 7
Minimum order quantity: 3
Multiple: 1
€ 1.08*
BKL Electronic 10120113 Pin connector + strain relief Contact spacing: 2.54 mm Total number of pins: 16 No. of rows: 2 1 pc(s)
2 x 8
Minimum order quantity: 5
Multiple: 1
€ 0.81*
BKL Electronic 10120114 Pin connector + strain relief Contact spacing: 2.54 mm Total number of pins: 20 No. of rows: 2 1 pc(s)
2 x 10
Minimum order quantity: 5
Multiple: 1
€ 0.81*
BKL Electronic 10120115 Pin connector + strain relief Contact spacing: 2.54 mm Total number of pins: 26 No. of rows: 2 1 pc(s)
2 x 13
Minimum order quantity: 3
Multiple: 1
€ 1.08*
BKL Electronic 10120117 Pin connector + strain relief Contact spacing: 2.54 mm Total number of pins: 40 No. of rows: 2 1 pc(s)
2 x 20
Minimum order quantity: 3
Multiple: 1
€ 1.25*
BKL Electronic 10120118 Pin connector + strain relief Contact spacing: 2.54 mm Total number of pins: 50 No. of rows: 2 1 pc(s)
2 x 25
Minimum order quantity: 2
Multiple: 1
€ 1.67*
Documents & Downloads
Datasheet
Datasheet 742204 BKL Electronic 10120116 Pin connector + strain relief Contact spacing: 2.54 mm Total number of pins: 34 No. of rows: 2 1
User & Safety Instructions
User & Safety Instructions 742204 BKL Electronic 10120116 Pin connector + strain relief Contact spacing: 2.54 mm Total number of pins: 34 No. of rows: 2 1
Description
Made of thermoplastic polyester, with fibre-glass reinforcement. DIN 41651. Also suitable for two-row pin connector strip in 2.54 mm grid.
Frequently Bought Together
(*All information is plus legal VAT) This article
BKL Electronic 10120116 Pin connector + strain relief Contact spacing: 2.54 mm Total number of pins: 34 No. of rows: 2 1
Conrad Electronic
€ 3.75*
HT-214 Squeezer Cut & Clip terminals
€ 12.60*
BKL Electronic 10120564 Pin strip no ejector Contact spacing: 2.54 mm Total number of pins: 34 No. of rows: 2 1 pc(s)
