Blickle 846924 PATH 160/12KA-ELS Wheel Wheel diameter: 160 mm Load capacity (max.): 260 kg 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Load capacity at 4 km/h: 260 kg
- Material wheel body: High-quality polyamide 6
- Material: Polyurethane lining
- Colour run lining: Dark gray
- Colour wheel body: Silver gray
- Temperature resistance up to 70 °C
- Temperature resistance min -20 oC
- Coating hardness 94 Shore A
- Without a trace: Yes
- Anti-static: No.
- Electrically conductive: Yes
- No discoloration of contact: Yes
- Stainless steel: No.
- Heat resistant: No.
- Autoclave-compatible: No.
- Resistant to hydrolysis: No.
- Product type
Wheel
- Wheel Ø
160 mm
- Load capacity (max.)
260 kg
- Axle hole diameter
12 mm
- Wheel width
40 mm
- Bearing type
Ball bearing
- Material
Polyurethane
- Factory colour
Dark grey
- Content
1 pc(s)
- Hub length
62 mm
- Weight
0.646 kg
Documents & Downloads
Datasheet
Datasheet 3058668 Blickle 846924 PATH 160/12KA-ELS Wheel Wheel diameter: 160 mm Load capacity (max.): 260 kg 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3058668 Blickle 846924 PATH 160/12KA-ELS Wheel Wheel diameter: 160 mm Load capacity (max.): 260 kg 1 pc(s)
Description
Wheel with thermoplastic polyurethane wood plank, with polyamide wheel body, with thread protection made of plastic, small, electrically conductive, trackless
Coating:
• High-quality thermoplastic polyurethane (TPU), hardness 94 shore A
• Low roll and swivel resistance
• very abrasion-resistant
• Colour dark gray, trackless, contact free
• Material-locking, undetachable connection with the wheel body
Wheel body:
• High-quality polyamide 6, unbreakable
• Colour silver gray
Other properties:
• With thread protection made of plastic, small
• Very high chemical resistance to many aggressive media
• Temperature resistance: -20 °C to +70 ° C, short term to +90 °C, reduced load capacity at over +35 °C.
• Electrical leakage (ohmic resistance) ≤ 104 Ω
This text is machine translated.
Coating:
• High-quality thermoplastic polyurethane (TPU), hardness 94 shore A
• Low roll and swivel resistance
• very abrasion-resistant
• Colour dark gray, trackless, contact free
• Material-locking, undetachable connection with the wheel body
Wheel body:
• High-quality polyamide 6, unbreakable
• Colour silver gray
Other properties:
• With thread protection made of plastic, small
• Very high chemical resistance to many aggressive media
• Temperature resistance: -20 °C to +70 ° C, short term to +90 °C, reduced load capacity at over +35 °C.
• Electrical leakage (ohmic resistance) ≤ 104 Ω
This text is machine translated.
